Conclusions: The two components analyzed have large reliability mar- gins for this use environment; a product with 30 chip carri- ers and 100 CC1820s would just reach a cumulative failure probability of 0.5% after 10 yea…
40//60°C) = 1000//2650 cycles, n(LCCC) = 30,
N
f
(0.5%, LCCC, ∆T = 40//60°C) = 127,000//15,400
cycles, β(LCCC) = 2, n(CC1820) = 100, N
f
(0.5%,
CC1820, ∆T = 40//60°C) = 43,000//21,000 cycles,
β(CC1820) = 4;
=>F
∑
(N = 3650) = 0.5%.
Thus, this design would just meet the reliability require-
ment of x ≤0.5% at the end of 10 years of service.
Accelerated Testing:
Test Components:
8 chip carriers (LCCC), 68 I/O 50-mil, α
C
= 6.3 ppm/°C
(measured), internally daisy-chained to allow indepen-
dent monitoring of each LCCC side (
1
⁄
4
of LCCC), with
side-brazed copper alloy compliant leads with a diago-
nal lead stiffness of K
D
= 52 lb/in (calculated), 256 chip
capacitors CC1820, α
C
= 6.8 ppm/°C (measured), with
metallization caps shorted with conductive epoxy on
capacitor top,
Test Substrate:
FR-4 multilayer board, α
S
= 16.0 ppm/°C (measured)
for greater CTE-mismatches and greater test accelera-
tion, test printed board lay-out provides for independent
continuity monitoring of each side of each chip carrier
(LCCC) and for continuity monitoring of groups of 8
chip capacitors (CCs) daisy-chained together. Confor-
mal Coating: Test vehicles are not conformally coated.
Test Parameters:
Temperature cycling from 0°C to 100°C at 24 cycles/
day, t
D
= 15 min, ∆T = 100°C and T
SJ
= 50°C.
Results of Accelerated Reliability Test:
N
f
(50%) = 982 and 6310 accelerated cycles-to-failure for
the individual LCCC sides and the 8 daisy-chained
CC1820s, respectively. Applying the partition correction
from Equation 16 in IPC-SM-785 results in N
f
(50%) =
491 and 10612 accelerated cycles-to-failure for the
actual LCCC and the CC1820 component attachments,
respectively.
Reliability Estimates by Extrapolation of Accelerated Test
Results:
Ceramic Chip Carrier:
The input parameters into Eq. A-4 are for the test: F =
1.0, K
D
= 52 lb/in, L
D
= 0.674 in, ∆(α∆T) = 970.0x10
-6
(α
C
= 6.3 ppm/°C, α
S
= 16.0 ppm/°C, T
C
=T
S
= 100°C,
T
C,0
=T
S,0
= 0°C), A = 900x10
-6
in
2
, h = 0.005 in;
-> ∆D(test) = 3.714x10
-2
.
and for the field use: F = 1.0, K
D
= 52 lb/in, L
D
= 0.674 in,
∆(α∆T) = 117.6x10
-6
//201.6x10
-6
(α
C
= 6.3 ppm/°C, α
S
= 10.5 ppm/°C, T
C
= 93°C, T
S
= 85°C, T
C,0
=T
S,0
=
45//25°C), A = 900x10
-6
in
2
, h = 0.005 in;
-> ∆D(use) = 5.459x10
-4
//1.604x10
-3
at ∆T = 40//60°C,
respectively.
The input parameters into Eq. A-2 are for the test: T
SJ
=
50°C (T
C
=T
S
= 100°C, T
C,0
=T
S,0
= 0°C), t
D
=15
min;
-> c(test) = −0.4160;
and for the field use: T
SJ
= 67//57°C (T
C
= 93°C, T
S
=
85°C, T
C,0
=T
S,0
= 45//25°C), t
D
= 715 min;
-> c(use) = −0.4751//−0.4691 at ∆T = 40//60°C, respec-
tively.
Using these results in Eq. A-12 in IPC-SM-785 with
N
f
(test, 50%) = 491 cycles gives:
=> N
f
(use, 50%) = 1,500,000//183,000 cycles at ∆T = 40//
60°C, respectively.
CC1820 Chip Capacitor:
The input parameters into Eq. A-3 are for the test: F =
0.7, L
D
= 0.080 in, ∆(α∆T) = 920.0x10
-6
(α
C
= 6.8
ppm/°C, α
S
= 16.0 ppm/°C, T
C
=T
S
= 100°C, T
C,0
=
T
S,0
= 0°C), h = 0.005 in;
-> ∆D(test) = 1.030x10
-2
.
and for the field use: F = 0.7, L
D
= 0.080 in, ∆(α∆T) =
148.0x10
-6
//222.0x10
-6
(α
C
= 6.8 ppm/°C, α
S
= 10.5
ppm/°C, T
C
=T
S
= 85°C, T
C,0
=T
S,0
= 45//25°C), h =
0.005 in;
-> ∆D(use) = 1.658x10
-3
//2.486x10
-3
at ∆T = 40//60°C,
respectively.
The input parameters into Eq. A-2 are for the test: T
SJ
=
50°C (T
C
=T
S
= 100°C, T
C,0
=T
S,0
= 0°C), t
D
=15
min;
-> c(test) = −0.4160;
and for the field use: T
SJ
= 65//55°C (T
C
=T
S,0
= 85°C,
T
C,0
=T
S,0
= 45//25°C), t
D
= 715 min;
-> c(use) = −0.4739//−0.4679 at ∆T = 40//60°C, respec-
tively.
Using these results into Eq. A-12 in IPC-SM-785 with
N
f
(test, 50%) = 10,612 cycles gives:
=> N
f
(use, 50%) = 148,000//73,000 cycles at ∆T = 40//
60°C, respectively.
Cycles-To-Failure for Daisy-Chains
Failure
No.
12345678
1
⁄
4
LCCC 146 196 388 418 486 540 568 628
8 CC1820 2718 3463 3826 4161 4397 4631 4738 5022
Failure
No.
9 10111213141516
1
⁄
4
LCCC 676 684 690 820 850 878 902 926
8 CC1820 5206 5372 5489 5598 5823 5978 6073 6223
Failure
No.
17 18 19 20 21 22 23 24
1
⁄
4
LCCC 1038 1044 1096 1122 1206 1214 1298 1350
8 CC1820 6397 Test terminated at 6,400 cycles
Failure
No.
25 26 27 28 29 30 31 32
1
⁄
4
LCCC 1386 1480 1536 1602 1716 1840 2002 2432
8 CC1820 Test terminated at 6,400 cycles
IPC-D-279 July 1996
46
Conclusions:
The two components analyzed have large reliability mar-
gins for this use environment; a product with 30 chip carri-
ers and 100 CC1820s would just reach a cumulative failure
probability of 0.5% after 10 years.
Excellent agreement between the reliability estimates from
analytical reliability model and from extrapolation from the
results of accelerated testing is shown.
