at one temperature, there may be no stress where two mate- rials join but at a dif ferent temperature, if there is a dif fer- ence in CTEs, the same joint may well be under such con- siderable strain that the part fractu…

uniform in thickness. Plating may be followed by a reﬂow

performed in hot oil. Dipped or reﬂowed solder ﬁnishes are

thinner at the corners of the terminations. Dipped solder

ﬁnish processes are sometimes followed by hot air ‘‘kniv-

ing’’ to obtain a uniform thickness of metal on the ﬂat por-

tion of the termination; the result is the thinner metal at the

corners. Copper terminations are commonly less solderable

at the corners due to exposed intermetallics and oxidation

of the intermetallics more quickly than areas with thicker

tin-lead coating.

5.4.3 Termination Recommendations When Using Elec-

trically Conductive Adhesives

Where electrically con-

ductive adhesive is used, component termination ﬁnishes of

silver, gold or palladium are recommended, since silver

oxide is conductive and gold and palladium do not oxidize.

Tin, lead, or tin-lead terminations are not recommended,

particularly when the service environment exposes the

joints to humidity. The moisture permeates the adhesive

and oxidizes the adhesive/metal interface, increasing the

series resistance.

5.4.4 Gold, Palladium, Silver Termination Finishes

Where gold or palladium plating is used, the gold or palla-

dium content in the solder joint should be less than 3 wt%.

This level can generally be met if the gold or palladium

ﬁnish is ~0.1 µm thick on both the component termination

and the printed board. Alternatively, the component termi-

nations can be dipped in solder to remove the gold; the

solder bath must be monitored to prevent excessive gold

buildup. The presence of gold plating on the printed board

might be driven by the use of pressure contacts such as

solder-less or edge connectors.

Copper leads should be separated from gold overplating by

a pore-free barrier of nickel plating to prevent diffusion of

the copper into the gold; oxidation of diffused copper

degrades the solderability of the gold ﬁnish.

Where thin, uniform, solderable platings are needed which

can be exposed to high temperatures without loss of solder-

ability, precious metal platings are chosen. Silver, palla-

dium and gold are some of the precious metals available.

Gold is the best of these materials having excellent solder-

ability and the best shelf life (indeﬁnite). However, it is

expensive and prone to intermetallic failure. Gold requires

a barrier layer of nickel plating, ~1.5 µm thick, to prevent

diffusion of copper to the surface of the gold which

degrades solderability.

Gold plating requires a careful soldering process to avoid

formation of intermetallic phases which may embrittle the

solder joint and lead to premature failure. Surface mounted

solder joints are more susceptible to embrittlement failure

because of the limited amount of solder in the joint and the

reliance on the solder joint for mechanical strength. The

concentration of the gold in the tinning bath needs to be

monitored to prevent the gold concentration from exceed-

ing 3 wt%.

Silver requires care in handling and storage to avoid tar-

nishing which can interfere with solderability.

5.5 Solderability of Termination Finishes Solderability

describes an observed condition which results from the use

of a ﬂux together with a component termination ﬁnish or

printed board land pattern ﬁnish under the inﬂuence of a

heat source.

The period of time over which tin-lead ﬁnishes demon-

strate acceptable solderability depends upon the plating

thickness, plating conditions and storage conditions; sol-

derability decreases with increases in such factors as tem-

perature, humidity and oxygen content. Benign atmo-

spheres and proper storage conditions may result in a shelf-

life on the order of years. Some plated systems are

unsolderable after several months under factory ﬂoor con-

ditions. Techniques for evaluating and quantifying soldera-

bility are found in J-STD-002, Solderability Tests for Com-

ponent Leads, Terminations, Lugs, Terminals and Wires.

Organic contamination such as oil, grease, and ﬁnger prints

or particulate contamination such as dust can also degrade

solderability. The mild no-clean or ‘‘leave-on’’ ﬂuxes may

not be effective in the presence of these contaminants.

Co-deposited organic materials (electroplating brighteners

and levelers) will shorten the solderable shelf life of the tin

or tin-lead plating.

Tarnished ﬁnishes may be difficult to solder and result from

the reaction of a silver termination ﬁnish with sulfur com-

pounds which may be emitted by chemical processes using

sulfur or storage containers made from paper containing

residual sulfur compounds. Silver-plated terminations

should be stored with an oxidation inhibitor.

Assure solderability through testing by the producer. The

wetting balance method permits measurement of the time-

for-wetting as well as the degree of wetting. This testing

provides a reproducible method of evaluating process vari-

ables with a standard sample geometry. At this time, inter-

pretation of the results varies. A cheaper, non-quantitative

test is visual examination of the solder tinned surface (‘‘dip

and look’’).

5.6 Soldering Considerations SMDs must withstand the

higher solder process temperatures and must be selected,

placed and soldered more carefully to achieve acceptable

manufacturing yield. See also Appendix D, Components

and PSMCs.

5.7 CTE Mismatch Considerations Difference in the

coefficient of thermal expansion (CTE) of the materials of

an SMD is very important to its reliability. This is because

IPC-D-279 July 1996

at one temperature, there may be no stress where two mate-

rials join but at a different temperature, if there is a differ-

ence in CTEs, the same joint may well be under such con-

siderable strain that the part fractures.

Matching the CTEs at a joint is no guarantee of freedom

from the problem because electronic components are their

own heat sources and because there is a temperature differ-

ence between component and substrate. The problem is

directly related to the size of the component, the thickness

of a solder joint and the compliance of the lead. See Sec-

tion 3.4 and Appendix A. The major problem arises from

thermally induced cyclic stress in the solder joint of the

larger leadless ceramic chip carrier (LLCCC) components.

5.8 ESD Packaging Requirements All SM pick-and-

place feeder parts, sensitive or not, if they are dispensed

adjacent to ElectroStatic Discharge Susceptible (ESDS)

components, should be packaged in antistatic materials.

5.9 Specials or Custom Devices Use Precaution

Devices with unusual or exotic characteristics, extremely

tight speciﬁcations, or low volume ‘‘custom’’ processing

are not as reliable as ‘‘standards.’’ The tightened speciﬁca-

tions result in a smaller or unknown C

. The unique pro-

cess of evaluation and selection used to meet special

requirements is more vulnerable to errors. It is very diffi-

cult to demonstrate product quality and reliability (or to

improve the process) with low volume of product.

5.10 Components to Avoid or to Use with Caution

• Printed board with T

< 125°C

• Printed board with PTH and PTVs aspect ratio > 3:1

• Components not on the preferred parts list

• Components using obsolete technologies

• Components containing liquid and sealed only with

rubber

• Components with rotating seals

• Components with thick silver or gold plating or paste

as the solderable termination

• Components with corrosive or polar liquids

• Aluminum electrolytics with silver anode (obsolete

technology)

• Components with exposed moving electrical contacts

• Electro-Mechanical connections between contact ﬁn-

ishes of tin and gold (dissimilar metals)

• Film resistors trimmed more than 50%

• Multilayer ceramic components such as capacitors,

inductors, ﬁlter networks assembled into PWAs using

assembly processes with ∆T/∆t > 4°C/second.

• Solder immersion or wave soldering of surface mount

components other than simple chip resistors and chip

capacitors.

• Components with ESD susceptibility

• Variable resistors, particularly wire-wound

• Variable capacitors

• Multilayer capacitors trimmed to value

5.11 Component Selection Considerations for Military

and Space Applications

Military and aerospace applica-

tions exposed to severe environments may require pack-

ages that are more robust. Hermetic packages may be

required to be robust to a life cycle environment which

includes high relative humidity. However, under extreme

levels of shock and vibration, hermetic packages (with ﬂy-

ing internal leads) are less robust than plastic encapsulated

packages. See Appendix P.

6.0 SOLDER MASK AND CONFORMAL COATING

CONSIDERATION

Because of the ﬁne lines and close conductor spacing and

the assembly processes utilized in SMT, solder mask and

conformal coatings may be a new design requirement. Sol-

der mask performs two functions, one to limit the ﬂow of

solder paste, the other to protect adjacent traces from cor-

rosion. Conformal coating protects the solder joints and

component conductors from corrosion. Detailed descrip-

tions of solder masks and conformal coatings may be found

in Appendix N.

6.1 Solder Mask Considerations for SM The decision to

use solder mask for surface mount technology applications

is usually based upon the need to prevent migration of sol-

der away from the device pads during solder reﬂow. An

alternative to the use of solder mask is a pads-only

approach.

Typically, solder mask openings are designed 125 µm

larger than the component land or through-hole pad. This

allows for alignment tolerances during solder mask pro-

cessing. Since solder mask or its residue on surface mount

pads will reduce the size of the solder ﬁllet, it is highly

recommended that printed boards be procured which

exclude solder mask from extending onto these areas.

The ‘‘do’s’’ and ‘‘don’ts’’ of solder mask are important ele-

ments in the construction of a reliable surface mount

assembly. The type, thickness, coverage areas and proper

application are essential parameters in this complex equa-

tion. Since surface mount design begins to encroach upon

the limits of the solder mask process, it is important for the

designer to understand solder mask process capabilities.

The solder mask must be compatible with the surface

mount processes being used, especially the heat and sol-

vent resistance characteristics. The choice of a particular

solder mask should be validated with the proposed assem-

bly processes (reﬂow, wave and rework soldering; clean-

ing, conformal coating) to ensure that there are no adverse

July 1996 IPC-D-279

interactions. Failure to understand the links between board

manufacture, assembly processes and circuit design may

result in a choice of solder mask which will be costly to

reverse after introduction.

6.1.1 Solder Mask Selection Table 6-1 provides guide-

lines on solder mask selection.

6.1.2 Solder Mask Thickness Issues Regardless of the

type of solder mask used for surface mount applications,

the solder mask must be the correct thickness and consis-

tent. Solder mask plays an important role in forming a gas-

ket between the solder paste stencil and the printed board

to reduce the extrusion of paste and limiting smearing.

Typical dry ﬁlm solder masks range from 75 to 100 µm

thick, leaving the mask higher than the surface mount pads

(see Figure 6-1). Thus, the stencil will rest on the solder

mask and leave a gap between the stencil and the pads

through which solder paste can ﬂow. However, typical liq-

uid photoimageable masks range from 15 to 30 µm thick.

This makes the pad surfaces the highest points on the board

so that when the stencil is lowered, it will rest on the pads.

The stencil then gaskets the opening around the pads, pre-

venting the solder paste from getting under the stencil.

Excessively thick solder mask, particularly dry ﬁlm over

traces under components with small clearance, can contrib-

ute to the formation of crevices which entrap ﬂux. In the

case where the solder mask touches the bottom of the com-

ponent, if insufficient solder paste is used, it may result in

chip component drawbridging (tombstoning), insufficient

solder ﬁllet or lack of solder joint. (See IPC-SM-782 and

IPC-D-275)

Solder joint reliability under temperature cycling or power

cycling conditions may be reduced if the solder mask

touches the bottom of the component or conformal coating

ﬁlling the printed board-component gap. (See IPC-SM-

785.)

6.2 Temporary Solder Mask and Tapes Temporary sol-

der mask and tapes are used to prevent solder and solvents

from causing problems during assembly processes. In SMT

the reﬂow techniques may expose the mask or tape to tem-

peratures which may cause thermal breakdown. This may

cause reversion of some materials into a sticky ‘‘goo’’ and

others may adhere tenaciously making them difficult to

remove. The cleaning of SM assemblies may also be more

aggressive than through-hole. It is necessary to verify that

the temporary mask selected is compatible with the assem-

bly processes.

6.3 Conformal Coatings The primary purpose of confor-

mal coatings is to provide environmental protection. Some

conformal coatings have been shown to signiﬁcantly affect

the reliability of surface mount solder joints. Parylene

(trademark of Union Carbide, chemical name Polyparaxy-

lylene) and silicone conformal coating have been shown to

improve accelerated fatigue life of SM solder joints by

approximately a factor of two or three. However in thermal

shock, some silicone coatings have been reported to

decrease life in thermal shock.

7.0 ASSEMBLY PROCESSES AND DESIGN FOR MANU-

FACTURABILITY

While there are only a few processes used in fabricating an

assembly with SMT components, these processes directly

impact the formation of the solder joint that provides the

reliable attachment of the part to the substrate. It is essen-

tial that the designer of surface mount assemblies under-

stand the manufacturing processes involved, including their

impact on the reliability of the completed assembly. Design

for manufacturability requires that the designer have a clear

view of the impact and limitations of the fabrication steps.

IPC-CM-770, Printed Board Component Mounting,

includes the following classiﬁcation scheme for surface

mount assemblies:

Type 1 —Components (mounted) on only one side of

Table 6−1 Solder Mask Guidelines

RECOMMENDED FOR THESE SM SOLDERING

PROCESSES

SOLDER MASK TYPE

APPLICATION

METHOD THICKNESS

TENTED

VIAS

STANDARD

PITCH

REFLOW

FINE

PITCH

REFLOW

WAVE

SOLDER

Liquid Screenprint 8-50 µm N* N N N

Dry Film Hot roll Lamination 60-100 µm Y Y N Y

Liquid Photoimageable Open Screen Coat

Curtain Coat

Roller Coat

Electrostatic Spray

15-30 µm N Y Y Y

Combination (liquid

photoimageable* dry

ﬁlm cap layer)

Lamination 50-75 µm Y N Y

*The majority of via holes can be ﬁlled by this process but not tented.

IPC-D-279 July 1996
