NPM- TT2 EJM1EE-MB-02 T-02 Priming shot Tape feed Priming shot Tape Exh. Priming shot Recog Error Error Messag e Troubleshooting 2-1-3 Single stop errors 19 Error Code Error Message Cause Inspection and Solution Error oc…

100%1 / 332
NPM-TT2 EJM1EE-MB-02T-02
feederMemory Write Error
Joint Detect Error
Tape Jamming Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
The cover tape jammed in
the mechanism or some
other trouble occurred.
(Single stop error occurred.)
1) Make sure the reel is properly
installed.
2) Make sure the tension sensor is
working properly.
40414
The tape joint was not
properly detected.
(Single stop error occurred.)
Take any of the following measures:
1) Make sure the reel is properly
installed.
2) Make sure the joint detection
sensor is working properly.
40415
Failed to write the
component information to the
feeder memory.
(Single stop error occurred.)
Check the feeder.
40416
2-1-3-36
NPM-TT2 EJM1EE-MB-02T-02
Priming shot Tape feed
Priming shot Tape Exh.
Priming shot Recog Error
Error
Messag
e
Troubleshooting
2-1-3
Single stop errors 19
Error Code
Error Message
Cause Inspection and Solution
Error occurred during
priming shot recognition.
(Single stop error occurred.)
Take any of the following measures:
1) Perform priming shot teaching
and check the condition of priming
shot.
2) Correct the parameter(s) that
caused the error.
40417
Tape of the priming shot unit
broke.
(Single stop error occurred.)
Take any of the following measures:
1) Change the tape.
2) Perform priming shot teaching
and check if the tape is properly
fed.
40418
Error occurred during feeding
tape of priming shot unit.
(Single stop error occurred.)
Perform priming shot teaching and
check if the tape is properly fed.If
the error persists, contact PFSC.
40419
2-1-3-37
NPM-TT2 EJM1EE-MB-02T-02
Stamper return origin
Error
Stamper unit initial error
The trans unit is not set up.
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Transcript unit cannot be
confirmed.
(Single stop error occurred.)
Take any of the following measures:
1) Make sure the transcript unit is
set properly.
2) Remove and insert the transcript
unit.
40421
Failed to Initialize the
transcript unit properly.
(Single stop error occurred.)
Take any of the following measures:
1) Check the transcript unit.
2) Remove the transcript unit and
insert it again.
40422
Failed to return the transcript
unit to origin properly.
(Single stop error occurred.)
Take any of the following measures:
1) Check the transcript unit.
2) Remove the transcript unit and
insert it again.
40423
2-1-3-38
