NPM- TT2 EJM1EE-MB-02 T-02 Support Plate Pos ition Error (Right) Support Plate Pos ition Error (Left) Solutions to errors Error Code Error Message Cause Inspection and Solution The support plate has not lowered completel…
NPM-TT2 EJM1EE-MB-02T-02
Tape cover detection2
(Rear)
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 7
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 2 is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 2 of the
table is OFF when the light from
emitter is blocked and ON when
the light from the emitter reaches
the detector. At this time, make
also sure that the green LED is lit
when the light from the emitter is
blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1321
2-1-4-12
NPM-TT2 EJM1EE-MB-02T-02
Support Plate Position
Error
(Right)
Support Plate Position
Error
(Left)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
The support plate has not
lowered completely.
(Interlock occurred.)
Take any of the following measures:
1) Check the grease condition of the
up/down shaft.
2) Remove any foreign body
between the table and machine
base.If the error persists, the
sensor may be displaced or at fault.
Contact PFSC.
1322
The support plate has not
lowered completely.
(Interlock occurred.)
Take any of the following measures:
1) Check the grease condition of the
up/down shaft.
2) Remove any foreign body
between the table and machine
base.If the error persists, the
sensor may be displaced or at fault.
Contact PFSC.
1323
2-1-4-13
NPM-TT2 EJM1EE-MB-02T-02
Nozzle Interference Area
Intrusion
(Rear Side Front Row)
Nozzle Interference Area
Intrusion
(Front Side Rear Row)
Nozzle Interference Area
Intrusion
(Front Side Front Row)
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 8
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Z-axis interference sensor
may be at fault or sensor
cable may be broken.
2) Y-axis interference sensor
may be at fault or sensor
cable may be broken.
(Interlock occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and if any problem is
found, contact PFSC.
1324
Any of the following causes
is likely:
1) Z-axis interference sensor
may be at fault or sensor
cable may be broken.
2) Y-axis interference sensor
may be at fault or sensor
cable may be broken.
(Interlock occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and if any problem is
found, contact PFSC.
1325
Any of the following causes
is likely:
1) Z-axis interference sensor
may be at fault or sensor
cable may be broken.
2) Y-axis interference sensor
may be at fault or sensor
cable may be broken.
(Interlock occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and if any problem is
found, contact PFSC.
1326
2-1-4-14
