NPM- TT2 EJM1EE-MB-02 T-02 Tape Cover Detection1 Error Messag e Troubleshooting 2-1-2 Self-diagnosis errors 2 Error Code Error Message Cause Inspection and Solution Tape cover sensor 1 is blocked. (Self-di agnosis erro r…
NPM-TT2 EJM1EE-MB-02T-02
Y Axis Interference
Conveyor Opening Sensor
Detect
Servo Switch Off
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Servo switch is OFF.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Turn the servo switch (One
position each at front side and rear
side) clockwise to turn it ON.
2) If the error persists even after the
servo switch is turned ON, the
switch may be broken.Contact
PFSC.
40004
Transfer opening sensor is
OFF.
(Self-diagnosis error
occurred.)
Check the condition of the adjoining
machines.Choose [Machine] -
[Adjust] - [All] - [Input confirm] and
check the condition of the transfer
opening sensor.
40005
Front side XY unit and the Y-
axis of the rear side XY unit
interfered with each other.
(Self-diagnosis error
occurred.)
If the error persists even after the
front side and rear side XY unit are
separated, contact PFSC.
40006
2-1-2-2
NPM-TT2 EJM1EE-MB-02T-02
Tape Cover Detection1
Error
Messag
e
Troubleshooting
2-1-2
Self-diagnosis errors 2
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 1 is
blocked.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 1 of the
table is OFF when the light from
the emitter is blocked, and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked, and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
40007
2-1-2-3
NPM-TT2 EJM1EE-MB-02T-02
Tape Cover Detection2
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 2 is
blocked.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 2 of the
table is OFF when the light from
the emitter is blocked, and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked, and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
40008
2-1-2-4
