NPM- TT2 EJM1EE-MB-02 T-02 Solutions to errors Code Message Cause Solution 2-2- 3 Bad head set It is displayed when an head is set as a bad head on the bad head setting screen. 1.Check the bad head cond itions. 2.After t…
NPM-TT2 EJM1EE-MB-02T-02
Error
Message
Troubleshooting
2-2
Warning message 2
Code
Message
Cause Solution
Retry sequence change
3906
Support pin auto
change warn.
4003
Thickness no meas.
warn.
4015
2-2-2
When any of the following
factors contributes to the
failure to perform placement
according to production data,
the warning appears.
･Conditions of the right end
of the feeder
･Difference in transcript
mode
･Pickup limits
･Adjoining limits
･Mix of presence/absence of
division recognition
･Difference in recognition
type, etc.
If the warning continues to appear,
repeat optimization.
This is the warning that
appears when the support
pins have not been replaced
yet that need replacing. (It
appears when the pin
arrangement is not based on
production data.)
Temporarily stop the auto running,
then restart it and ensure that the
support pins are replaced
successfully.
Thickness measurement
using the vertical line camera
is set on a per-turn action
basis.
Even when only a single
component whose “Thick
measure” is set to “ON” is
present in the same turn,
thickness will be measured
for all components. At that
time, if there is disagreement
between the thickness and
measured value of a
component with its “Thick
measure” set to “OFF”, the
warning appears.
There may be disagreement
between the height and thickness of
a component without thick measure.
If necessary, check the component
thickness within production data and
the thickness of the actual
component.
NPM-TT2 EJM1EE-MB-02T-02
Solutions to errors
Code
Message
Cause Solution
2-2-3
Bad head set
It is displayed when an head
is set as a bad head on the
bad head setting screen.
1.Check the bad head conditions.
2.After the problem has been
resolved, cancel the bad head
settings on the bad head setting
screen.
4037
Syringe trans empty
warn
Transfer material becomes
short.
Supply the transfer material.
5211
Can't measure cart
height
Failed to measure the cart
height.
The cart height cannot be
measured properly because
the nozzle installed to the
measurement head gets
clogged.
Check clogging of the nozzle
installed to the measurement head.
5225
No PCB warp measure
height.
It is displayed in the following
cases:
･When “PCB warpage
detection” of software
switch in the production
data is set to “ON” and
“Height sensor” of the
option setting is set to
“OFF”.
･When “PCB warpage
detection” is “ON” and
“Height sensor” of the
option setting is “None”.
Confirm the production data and
details of the optional settings.
5668
NPM-TT2 EJM1EE-MB-02T-02
Error
Message
Troubleshooting
2-2
Warning message 3
Code
Message
Cause Solution
Free arrange sequence
change
A process of feeder free
arrangement is executed.
A feeder is set to the feeder
address which is not
specified by the production
data, and production
continues.
To disable an feeder free
arrangement operation, set the
feeder again according to the
production data.
5798
Feeder reset SW
The feeder reset switch has
been detected.
Because pickup of the
applicable feeder is not
performed (skipped), the
feeder can be pulled out.
Pull out the feeder, and confirm the
feeder state and replenish parts.
5815
No PCB warp
correction
It is displayed in the following
cases:
･When “PCB warpage
detection” of software
switch in the production
data is set to “ON” and
“PCB warpage correction”
of the option setting is set
to “OFF”.
･When “PCB warpage
information receipt” of the
communication setting is
set to “ON” and “PCB
warpage correction” of the
option setting is set to
“OFF”.
Confirm the production data and
details of the optional settings.
5918
Feeder firm Version
Warning
The feeder firmware version
does not match the machine
software version.
Upgrade the feeder firmware
version.
6133
2-2-4
