NPM-TT2 EJM1EE-MB-02T-02
Camera IF board Device
driver error
IspBox SubSys Time out
error
IspBox SubSys Error
IspBox SubSys Production
data error
IspBox SubSys Production
data error
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 45
Error Code
Error Message
Cause Inspection and Solution
Invalid content was found in
the production data.
(Invalid production data.)
Create the production data again.
Then, download the production data
again.
1896
Failed to get the view data.
(Failed to get the view data.)
Check the applicable components
for inspection in the production data
and download the data again.
1897
Improper procedure was
taken in software processing.
(Inspection box system error
occurred.)
Restart the machine. If the error
persists, contact PFSC.
1898
Improper procedure was
taken in software processing.
(Timeout occurred in
software processing.)
Restart the machine. If the error
persists, contact PFSC.
1899
Improper procedure was
taken in software processing.
(Camera IF board driver
aborted.)
Restart the machine. If the error
persists, contact PFSC.
1900
2-1-4-88
NPM-TT2 EJM1EE-MB-02T-02
Camera IF board Camera
parameter set error
Camera IF board Light
spot correction table set
error
Camera IF board Binary
table set error
Camera IF board Camera
capture parameter error
Camera IF board
Initialization error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Capture board could not be
initialized.
(Failed to initialize the
camera IF board.)
Check the connection of the camera
link cable between the inspection
head and inspection box.
1901
Improper procedure was
taken in software processing.
(Failed to obtain the capture
parameter.)
Restart the machine. If the error
persists, contact PFSC.
1902
Improper procedure was
taken in software processing.
(Failed to set the binary table
of the camera IF board.)
Restart the machine. If the error
persists, contact PFSC.
1903
Improper procedure was
taken in software processing.
(Failed to set the light spot
correction table of the
camera IF board.)
Restart the machine. If the error
persists, contact PFSC.
1904
Improper procedure was
taken in software processing.
(Failed to set the camera
parameters of the camera IF
board.)
Restart the machine. If the error
persists, contact PFSC.
1905
2-1-4-89
NPM-TT2 EJM1EE-MB-02T-02
IspBox MainSys PCB skip
notification command
error
Camera IF board DMA
transfer error
Camera IF board
Exposure finish
information deal error
Camera IF board
Exposure finish
information start error
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 46
Error Code
Error Message
Cause Inspection and Solution
Improper procedure was
taken in software processing.
(Failed to set the exposure
completion notice of the
camera IF board.)
Restart the machine. If the error
persists, contact PFSC.
1906
Exposure finish information
could not be received.
(Failed to receive the
exposure completion notice
of the camera IF board.)
Check the connection of the camera
link cable.
1907
Image transfer from the
camera IF board to the
inspection box PC failed.
(Failed in DMA transfer of
image from the camera IF
board.)
Check the connection of the camera
link cable.
1908
Improper procedure was
taken in software processing.
(PCB skip information
command notified
incorrectly.)
Restart the machine. If the error
persists, contact PFSC.
1909
2-1-4-90
