NPM-TT2 EJM1EE-MB-02T-02
Tray action time up
non-collation
(verification2)
PartsTopSideRecCorrLim
Over
Nzl Height Last Val Diff
Err
Error
Messag
e
Troubleshooting
2-1-3
Single stop errors 24
Error Code
Error Message
Cause Inspection and Solution
The difference is over 0.1mm
compared to the last
measure result.
(Single stop error occurred.)
Check the mounting status of the
nozzle.Make sure that there is no
foreign body on the lens of the parts
recognition camera.Calibrate origin
offset Z-axis and multi recognition
camera offset.
40470
The offset position of
recognition object from parts
center is over the limit.
(Single stop error occurred.)
Please confirm if the following items
of head camera recognition
correction mount parameter are
set correctly in DGS.
1)The offset position of recognition
object from parts center
2)Limit
40471
Feeder which has been
pulled out and inserted^ but
has not executed verification
has been detected when
running starts.
(Single stop error occurred.)
Please start the production after
executing verification.
40472
Tray feeder action isn't
completed in specified time.
(Tray action time up)
Please confirm the tray feeder status.
40473
2-1-3-47
NPM-TT2 EJM1EE-MB-02T-02
Load measure result NG
Tape guide recognition
error
Tape guide mismatch
Tape setting incomplete
Tray abnormal
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Although the action is
requested to the tray feeder^
the action can't be executed
because the error is
notifiedfrom the tray feeder.
(Tray abnormal)
Please confirm the tray feeder status.
40474
Tape setting isn't completed
in specified time.
(Single stop error occurred.)
Please set the new tape from the
beginning.
40475
The kind of tape guide which
is set is different from the
recommended tape guide of
using parts.
(Single stop error occurred.)
Please confirm the set tape guide
kind.
40476
Failed in tape guide
recognition.
(Single stop error occurred.)
Please confirm the set tape guide
status.
40477
Mount load measure result
has exceeded NG range.
(Mount load measure result
NG)
Please confirm the nozzle status.
40479
2-1-3-48
NPM-TT2 EJM1EE-MB-02T-02
APC-MFB:
LNB process error
Error
Messag
e
Troubleshooting
2-1-3
Single stop errors 25
Error Code
Error Message
Cause Inspection and Solution
In LNB^ error occurred in
other company AOI check
result file convert process.
1:Data out of range 2:No
applicable parts error 3:File
format error(AOI check
result) 4:File format
error(NPM production data)
5:File access error^ other
(Single stop error occurred.)
･Error1,3Please confirm the
situation of the error occurred and
contact the AOI maker.･
Error21)Please confirm that NPM
and AOI production data are same
product.
2)Please confirm if the parts that is
not in the NPM production data
isn't checked by AOI.(Confirm
match of parts pattern number,
circuit number)
3)Please confirm the situation of the
error occurred and contact PFSC.･
Error4Please confirm the situation
of the error occurred and contact
PFSC.･Error51)Please confirm the
communication status between
LNB and AOI.2)Please confirm the
situation of the error occurred and
contact PFSC.
40484
2-1-3-49
