NPM- TT2 EJM1EE-MB-02 T-02 Multi Recog Camera FAN alarm Multi Recog Cam temperature w arning Multi Recog Cam voltage warning LW16-Nozzle Head θ PCB Fuse Disconne ction Error Messag e Troubleshooting 2-1-2 Self-diagnosis …

NPM-TT2 EJM1EE-MB-02T-02

LW16-Nozzle HeadθPCB

Temperature Error

LW16-Nozzle HeadθPCB

Voltage Error

LW16-Nozzle Head Z PCB

Fuse Disconnection

LW16-Nozzle Head Z PCB

Temperature Error

LW16-nozzle head Z PCB

Voltage Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Voltage at the LW16-nozzle

mount head Z-axis control

board has dropped

abnormally.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the voltage, and contact PFSC.

40158

CPU temperature at the

LW16-nozzle mount head Z-

axis control board has

exceeded the setting value.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the temperature, and contact PFSC.

40159

Fuse of the LW16-nozzle

mount head Z-axis control

board has blown.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the voltage, and contact PFSC.

40160

Voltage at the LW16-nozzle

mount head θ-axis control

board has dropped

abnormally.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the voltage, and contact PFSC.

40161

CPU temperature at the

LW16-nozzle mount head θ-

axis control board has

exceeded the setting value.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the temperature, and contact PFSC.

40162

2-1-2-44

NPM-TT2 EJM1EE-MB-02T-02

Multi Recog Camera FAN

alarm

Multi Recog Cam

temperature warning

Multi Recog Cam voltage

warning

LW16-Nozzle HeadθPCB

Fuse Disconnection

Error

Messag

Troubleshooting

2-1-2

Self-diagnosis errors 23

Error Code

Error Message

Cause Inspection and Solution

Fuse of the LW16-nozzle

mount head θ-axis control

board has blown.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the voltage, and contact PFSC.

40163

Voltage at the multi recog

camera control board has

dropped abnormally.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the voltage, and contact PFSC.

40164

CPU temperature at the multi

recog camera control board

has exceeded the setting

value.

(Self-diagnosis error

occurred.)

Choose [Machine] - [Information] -

[Firmware] - [Information] to check

the temperature, and contact PFSC.

40165

Fan of the multi recog

camera stopped.

(Self-diagnosis error

occurred.)

Because obstacle interfere with the

fan of multi recognition camera

inside or the fan at fault, please

contact PFSC.

40166

2-1-2-45

NPM-TT2 EJM1EE-MB-02T-02

DC power FAN alarm

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Fan of the DC power

stopped.

(Self-diagnosis error

occurred.)

Take any of the following measures:

1) Check the fan for any

interference with wiring, etc.

2) Make sure there is no

disconnected wire.

40167

2-1-2-46
