NPM- TT2 EJM1EE-MB-01 T-01 Misaligned placement What if Troubleshooting 1-1-2 Placement er ror 1 1-1-2 -1 Problem Cause Check/Solution Referen ce Nozzle error Component data error Pickup co ndition error Placement condit…
NPM-TT2 EJM1EE-MB-01T-01
Pickup error,
Stand pickup
(confirmation
items when the
pickup rate
decreases)
Feeder error
Nozzle selection
error
1-1-1-2
Nozzle error
Pickup condition
error
Nozzle selection
error
Tape splicing error
Cannot pickup
Problem Cause
Check/Solution Reference
What if
Operating
procedure
3-2-5, 4-1-13,
6-1-6
Maintenance
6-4
1.Check whether proper splicing
has been done. Adjust if
necessary.
2.Check whether the same
components are properly joined.
Adjust if necessary.
Tape Splicing
Operating
Instructions
2
1.Make sure that there is no
clogging, wearing down, or
chipping of the nozzle tip.
Replace the nozzle if you find
anything wrong with it.
2.Check for a sliding error of the
nozzle holder. Modify if
necessary.
3.Check whether the nozzle is
magnetized or not .
Demagnetize it if magnetized.
Maintenance
4-1-1
Operating
procedure
4-2-4, 4-2-6,
4-2-8
1-1-1-1 to 1-1-1-2
See [Cannot pickup]
Check whether the appropriate
nozzle has been selected
(component type and size).
If not, replace nozzle.
1-1-1-1 to1-1-1-2
See [Cannot pickup]
Check the vacuum pressure
(appropriate pressure:-87 to
-100kPa). If it is not within the
value, adjust the pressure.
Check the pickup position setting.
Adjust if incorrect.
-
-
Component data
error
DGS
Programming
Manual
6.5.3
1.Check whether the component
thickness has been input
properly. Adjust if necessary.
2.Check the amount of feed of the
feeder and the tape type (paper,
embossed paper) Adjust and
replace if necessary.
NPM-TT2 EJM1EE-MB-01T-01
Misaligned
placement
What if
Troubleshooting
1-1-2
Placement error 1
1-1-2-1
Problem Cause
Check/Solution Reference
Nozzle error
Component data
error
Pickup condition
error
Placement
condition error
Nozzle selection
error
Feeder error
PCB support
setting error
Poor PCB
Error in setting the
height of the placed
component
(interference with the
placed component)
Operating
procedure
2-5-3
Operating
procedure
6-1-4
DGS
Programming
Manual
4
DGS
Programming
Manual
6
1.Check whether the placement
retainer is set up properly. Fix it
if necessary.
2.Check whether the vacuum
breaking pressure is set properly.
Adjust it as needed.
3.Check whether XY coordinates
of the production data is set up
properly. Adjust it if not correct.
4.Check for the mounting timer
value.
Check whether component outline
and thickness, and dimensions of
each electrode are input correctly.
Adjust them if incorrect.
See 1-1-1-2
[Pickup error, Stand pickup]
1-1-1-1 to 1-1-1-2
See [Cannot pickup]
Check whether the PCB support
pins are properly positioned.
Adjust if necessary.
(Check that the PCB support pin
does not interfere with the
component)
Check the PCB upper surface
warpage.
If it warps too much, do not use it.
Check whether the placed
component height is set up
properly.
Fix it if necessary.
-
-
-
NPM-TT2 EJM1EE-MB-01T-01
1-1-2-2
Problem Cause
Check/Solution Reference
What if
Nozzle error
Error in setting the
height of the placed
component
(interference with the
placed component)
Pickup condition
error
Tape splicing error
Supply unit (feeder
or tray) setting
error or defect
PCB support setting
error
recognition mark
recognition error
Component data
error
Placement
condition error
Solder printing
condition error
(screen printer)
Recognition error
(misalignment, tilt)
1.Check the recognition image
(center and tilt) and an image of
an electrode. Adjust if necessary.
2.If the cover glass of the line
camera is contaminated, wipe it off.
recognition mark
recognition error
Solder printing
condition error
(screen printer)
DGS
Programming
Manual
5
1.Adjust if the recognition mark
setting (coordinate, shape and
imensions) s incorrect.
2.Correct the PCB stop position if
is aligned.
(e.g., check the length f the
placed component extending ff
the board)
Check the printing condition and
adjust the screen printer.
See 1-1-1-2
[Pickup error, Stand pickup]
1-1-1-1 to 1-1-1-2
See [Cannot pickup]
See 1-1-2-1 to 1-1-2-2
[Misaligned placement]
-
-
-
-
-
Component
missing
Misaligned
placement
