NPM-TT2 EJM1EE-MB-02T-02
Supply Position Pallet No.
Acquire Error
Pick-up Position Pallet No.
Acquire Error
Pallet Information Switch
Error
Defined Coordinate
Acquire Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Failed to obtain the
coordinates of TL/TP axes.
(Error obtaining defined
coordinates.)
Close the error screen and restart
production.If the error persists,
check the situation of the error
occurred and error message, and
contact PFSC.
2169
Failed to overwrite the pallet
information of pickup and
supply positions.
(Pallet information change
error occurred.)
Choose [Arrange] - [Parts prepare] -
[Tray] - [Check install] and check the
pallet Nos. set at the pickup and
supply positions of the tray and
correct them if necessary.
2170
Invalid pallet No. at the
pickup position.
(Pickup position pallet No.
acquisition error occurred.)
Choose [Arrange] - [Parts prepare] -
[Tray] - [Check install] and check the
pallet No. set at the pickup position
of the tray and correct them if
necessary.
2171
Invalid pallet No. at the
supply position.
(Supply position pallet No.
acquisition error occurred.)
Choose [Arrange] - [Parts prepare] -
[Tray] - [Check install] and check the
pallet Nos. set at the supply
position of the tray and correct them
if necessary.
2172
2-1-4-109
NPM-TT2 EJM1EE-MB-02T-02
Magazine Shutter Open
Error
Supply Section Shutter
Close Error
Supply Section Shutter
Open Error
Origin Offset Acquire Error
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 56
Error Code
Error Message
Cause Inspection and Solution
Failed to obtain origin offset
from the tray unit.
(Error obtaining origin offset.)
1) Check the connection with the
tray unit.
2) If the error persists, check the
situation of the error occurred and
error message, and contact PFSC.
2173
Supply shutter failed to close
or the limit switch failed to
detect the open shutter.
(Supply shutter open error
occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and check the
condition of the limit switch for
detecting the open/closed shutter.
2174
Supply shutter failed to open
or the limit switch failed to
detect the closed shutter.
(Supply shutter close error
occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and check the
condition of the limit switch for
detecting the open/closed shutter.
2175
Magazine shutter failed to
close or the limit switch failed
to detect the open shutter.
(Magazine shutter open error
occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and check the
condition of the limit switch for
detecting the open/closed shutter.
2176
2-1-4-110
NPM-TT2 EJM1EE-MB-02T-02
TP Axis Stroke Sensor
Detection
Pallet Misalignment Error
Magazine Shutter Close
Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Magazine shutter failed to
open or the limit switch failed
to detect the closed shutter.
(Magazine shutter close
error occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and check the
condition of the limit switch for
detecting the open/closed shutter.
2177
Pallet is partly out of the tray
magazine.
(Pallet misalignment error
occurred.)
Check the pallet position or the
sensor.
2178
TP-axis pullout position
sensor turned OFF.
(TP-axis stroke sensor
detection error occurred.)
Take any of the following measures:
1) Perform origin return again.
2) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and make sure the
TP-axis pullout sensor is turned
ON.
2179
2-1-4-111
