NPM- TT2 EJM1EE-MB-02 T-02 Cover Open (Front Security Switch) Servo Ready OFF Emergency Stop Switch ON Error Messag e Troubleshooting 2-1-2 Self-diagnosis errors 1 Error Code Error Message Cause Inspection and Solution E…
NPM-TT2 EJM1EE-MB-02T-02
Servo Ready OFF
Error Code
Error Message
Cause Inspection and Solution
Target axis is ready OFF.
(SelfCheck error happened.)
Please reset the axis.
40002
How to read the error message lists
Error message on the touchscreen
Error code No.
Error codes of emergency stop errors consist of category signs (two letters) and numbers
(four digits).
Category signs are listed in the previous page. Only numbers (4 digits) are displays in the list.
This section describes how to read the error message lists. If an error occurs while using the machine,
check the on-screen error message. See the error message lists (2-1-2 to2-1-4) to inspect and solve the error.
Before putting your hands into the machine to inspect and solve an error, be sure to turn OFF the servo
switch.
Causes of error Solutions
2-1-1-4
Solutions to errors
WARNING
Before putting your hands into the moving
parts for adjustments, turn the servo switch
OFF.
Risk of injury due to actuating the machine
abbreviation
Full name
abbreviation
Full name
IF
Interface
LNB
Line Network Box
ILK
Interlock
■Abbreviation displayed on the monitor
NPM-TT2 EJM1EE-MB-02T-02
Cover Open
(Front Security Switch)
Servo Ready OFF
Emergency Stop Switch
ON
Error
Messag
e
Troubleshooting
2-1-2
Self-diagnosis errors 1
Error Code
Error Message
Cause Inspection and Solution
Emergency stop switch has
been pressed.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Turn the emergency stop switch
clockwise to reset.(One position
each at front side and rear side)
2) If the machine fails to be restored
even after pressing the emergency
stop switch, the switch may be
broken.Contact PFSC.
40001
Applicable axis is not ready.
(Self-diagnosis error
occurred.)
Please inquire from PFSC.
40002
Safety cover is open.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2)If the error persists even after the
safety cover is closed, the safety
switch may be broken.Contact
PFSC.
40003
2-1-2-1
NPM-TT2 EJM1EE-MB-02T-02
Y Axis Interference
Conveyor Opening Sensor
Detect
Servo Switch Off
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Servo switch is OFF.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Turn the servo switch (One
position each at front side and rear
side) clockwise to turn it ON.
2) If the error persists even after the
servo switch is turned ON, the
switch may be broken.Contact
PFSC.
40004
Transfer opening sensor is
OFF.
(Self-diagnosis error
occurred.)
Check the condition of the adjoining
machines.Choose [Machine] -
[Adjust] - [All] - [Input confirm] and
check the condition of the transfer
opening sensor.
40005
Front side XY unit and the Y-
axis of the rear side XY unit
interfered with each other.
(Self-diagnosis error
occurred.)
If the error persists even after the
front side and rear side XY unit are
separated, contact PFSC.
40006
2-1-2-2
