NPM-TT2 EJM1EE-MB-02T-02
Tape Cover Detection4
Primary Source Power
Phase Connection
Error
Messag
e
Troubleshooting
2-1-2
Self-diagnosis errors 7
Error Code
Error Message
Cause Inspection and Solution
Primary power wiring may be
wrong.
(Self-diagnosis error
occurred.)
Make sure the primary power is
connected properly.
40029
Tape cover sensor 4 is
blocked.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 4 of the
table is OFF when the light from
the emitter is blocked, and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked, and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
40035
2-1-2-13
NPM-TT2 EJM1EE-MB-02T-02
Cover Open
Cover open
(Security sensor)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Safety cover is open.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be broken.Contact
PFSC.
40036
Safety cover is open.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be broken.Contact
PFSC.
40037
2-1-2-14
NPM-TT2 EJM1EE-MB-02T-02
Installed Head Non-
support Unit
(HeadOptDriveUnit)
No Installed Head
Error
Messag
e
Troubleshooting
2-1-2
Self-diagnosis errors 8
Error Code
Error Message
Cause Inspection and Solution
Head not installed.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Make sure the head is set
properly.
2) Choose [Machine] - [Information]
- [PnP] and make sure the head is
installed. If the error persists,
contact PFSC.
40038
Different head option drive
unit (changer^ calibration
stage^ priming shot unit)
installed.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Make sure the head option drive
unit has been set properly.
2) When the mounting head is
installed, attach the changer.When
the inspection head is installed,
attach the calibration stage.When
the dispenser head is installed,
attach the priming shot unit.
3) Choose [Machine] - [Information]
- [PnP] - [List] and check the
connection of the head option drive
unit.
40039
2-1-2-15
