NPM- TT2 EJM1EE-MB-02 T-02 Tape cover detection 1 (Front) Solutions to errors Error Code Error Message Cause Inspection and Solution Tape cover sensor 1 is blocked. (Interlock occurred.) Take any of the following measure…
NPM-TT2 EJM1EE-MB-02T-02
AMP Detect AC_FAIL
Error
Y Axis Interference
Servo Amplifier
Abnormality
(Rear Y axis)
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 9
Error Code
Error Message
Cause Inspection and Solution
Servo driver is at fault.
(Interlock occurred.)
1) Make sure there is no obstacle to
the XY unit and restart the
machine.
2) If the error persists, contact
PFSC.
1331
Front side XY unit and rear
side XY unit interfered with
each other.
(Interlock occurred.)
Separate them from the opposite XY
unit.
1332
Power supply may have
been stopped momentarily
due to power failure.
(Instantaneous power failure
occurred due to power
voltage of servo amplifier)
Check the voltage of the power
supply in the plant. Return to the
main menu and restart production. If
the error persists, contact PFSC.
1333
2-1-4-16
NPM-TT2 EJM1EE-MB-02T-02
Tape cover detection1
(Front)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 1 is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 1 of the
table is OFF when the light from
the emitter is blocked and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1334
2-1-4-17
NPM-TT2 EJM1EE-MB-02T-02
Tape cover detection1
(Rear)
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 10
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 1 is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 1 of the
table is OFF when the light from
the emitter is blocked and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1335
2-1-4-18
