NPM-TT2 EJM1EE-MB-02T-02
Action Command Error
Successive Action Setting
Error
Position Range Setting
Error
Axis Action Error
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 16
Error Code
Error Message
Cause Inspection and Solution
Improper procedure was
taken in software processing.
(Movement command issued
while the axis was moving.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1550
Improper procedure was
taken in software processing.
(Minimum value set in the
position range is greater than
the maximum value.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1557
Improper procedure was
taken in software processing.
(Incorrect parameter setting
values.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1558
Improper procedure was
taken in software processing.
(Undefined command
issued.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1559
2-1-4-30
NPM-TT2 EJM1EE-MB-02T-02
(+) Limit Error
Servo Off Error
Servo Ready Off Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Power to the servo
amplifier is not ON.
2) Axis movement may not
be performed due to
interlock of the adjoining
machine.
(Servo amplifier failed to get
ready.)
Take measures shown with the
same number as that of the cause.
1) Make sure the power to the servo
amplifier is turned ON. If the power
is ON, turn the machine power
back ON and start production.
Check the situation of the error
occurred and error message, and
contact PFSC.
2) Release the safety device of the
adjoining machine.
1561
Any of the following causes
is likely:
1) Axis movement was
disabled because it was
attempted with the Servo
Switch Off.
2) Axis movement failed due
to interlock of the adjoining
machine.
(Servo Off error occurred.)
Take measures shown with the
same number as that of the cause.
1) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check the
input condition of the servo switch.
2) Release the interlock of the
adjoining machine.
1562
Plus limit sensor was
blocked while moving in the
(+) direction.
(Axis stopped.)
Move the axis in the (-) direction and
unblock the limit sensor. Check the
mounting condition of the (+) limit
sensor. If the error persists, contact
PFSC.
1563
2-1-4-31
NPM-TT2 EJM1EE-MB-02T-02
(+)Software Limit Error
Absorb Clear Error
Teaching Speed Update
Command Issue Error
Return To Origin Error
(-) Limit Error
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 17
Error Code
Error Message
Cause Inspection and Solution
Minus limit sensor was
blocked while moving in the
(-) direction.
(Axis stopped.)
Move the axis in the (+) direction
and unblock the limit sensor. Check
the mounting condition of the (-) limit
sensor. If the error persists, contact
PFSC.
1564
Origin return has not been
completed because the origin
position of the motor cannot
be found.
(Origin return failed to
complete properly.)
Check the origin sensor for proper
wiring and make sure the sensor is
not broken.
1566
Improper procedure was
taken in software processing.
(Parameter error occurred in
update of the teaching speed
during machine stop.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1567
Improper procedure was
taken in software processing.
(Absorb clear was issued
during servo lock.)
Turn the machine power back ON
and start production. Then, check
the situation of the error occurred
and error message, and contact
PFSC.
1568
Plus soft limit was exceeded
during movement in the (+)
direction.
(Axis stopped.)
Move the axis in the (-) direction and
clear the (+) soft limit. If the error
persists, contact PFSC.
1570
2-1-4-32
