NPM- TT2 EJM1EE-MB-02 T-02 Cover O pen (Rear Side Safety switch this side) Cover Open (Front Side Safety switch this side) Error Messag e Solutions to errors Troubleshooting 2-1-4 Emergency stop errors 1 Error Code Error…

100%1 / 332
NPM-TT2 EJM1EE-MB-02T-02
F Proc. Eject detection
error
Timer safety relay
abnormal
Rear moveable cover
open or close action
incomplete error
Front moveable cover
open or close action
incomplete error
Error
Messag
e
Troubleshooting
2-1-3
Single stop errors 51
Error Code
Error Message
Cause Inspection and Solution
Because the Front moveable
cover open or close action is
incomplete^ XY action can't
be executed.
(Interlock occurred.)
Please confirm if the Front
moveable cover action is executed
correctly in Arrange-PartsPrepare-
Feeder screen.
44033
Because the Rear moveable
cover open or close action is
incomplete^ XY action can't
be executed.
(Interlock occurred.)
Please confirm if the Rear moveable
cover action is executed correctly in
Arrange-PartsPrepare-Feeder
screen.
44034
Because the timer safety
relay is time out.
(Interlock occurred.)
Please connect the cart or close the
moveable cover.
44035
In the setting of
communication between
MC^ because the PCB is
carried in before the
detection of the ejection
signal from the pre process
equipment^ error occurred.
(The ejection signal isn't
detected from the pre
process equipment.)
Please take any of the following
measures:
1)Please confirm the setting of
communication between MC.
2)Please confirm the ejection signal
output setting of pre process
equipment.
44036
2-1-3-101
NPM-TT2 EJM1EE-MB-02T-02
Cover Open
(Rear Side Safety switch
this side)
Cover Open
(Front Side Safety switch
this side)
Error
Messag
e
Solutions to errors
Troubleshooting
2-1-4
Emergency stop errors 1
Error Code
Error Message
Cause Inspection and Solution
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1302
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1303
2-1-4-1
NPM-TT2 EJM1EE-MB-02T-02
Safety Device Detect
(Post Proc)
Safety Device Detect
(Pre Proc)
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 2
Error Code
Error Message
Cause Inspection and Solution
Adjoining machine in the
previous process has been
turned OFF or emergency
stop switch has been
pressed.
(Interlock occurred.)
Take any of the following measures:
1) Turn ON power if the main switch
of the adjoining machine in the
previous process is OFF.
2) Reset the emergency stop switch
of the adjoining machine in the
previous machine if pressed.
1304
Adjoining machine in the
next process has been
turned OFF or emergency
stop switch has been
pressed.
(Interlock occurred.)
Take any of the following measures:
1) Turn ON power if the main switch
of the adjoining machine in the
next process is OFF.
2) Reset the emergency stop switch
of the adjoining machine in the
next process machine if pressed.
1305
2-1-4-2
