NPM-TT2 EJM1EE-MB-02T-02
Communication Error
Parameter Error
Command Error
Motion Incomplete
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Movement command was
issued before positioning
was completed.
(Head fails to move
properly.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1703
Improper procedure was
taken in software processing.
(Nonexistent head command
was issued.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1704
Improper procedure was
taken in software processing.
e.g.: 2 has been set although
available parameter is 0 or 1.
(Invalid parameter setting.)
Close the error screen and restart
production. Then, check the
situation of the error occurred and
error message, and contact PFSC.
1705
Check sum error occurred in
the communication data from
the host to the head.
(Communication error
occurred.)
Clean the drawer connectors for
connecting head, and check the
wiring connected to them. If the
error persists, contact PFSC.
1706
2-1-4-55
NPM-TT2 EJM1EE-MB-02T-02
Overload Anomaly(R)
Over Current Anomaly(L)
Encoder Disconnect
Anomaly(L)
Overload Anomaly(L)
Origin Return Abnormality
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 29
Error Code
Error Message
Cause Inspection and Solution
Origin return failed to be
completed within the
prescribed time and timeout
occurred.
(Head axis did not properly
return to origin. )
Check the situation of the error
occurred and error message, and
contact PFSC.
1707
Positional deviation with
power ON or integrated
current is beyond the
specified value.
(Head movement stopped
due to overload.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1708
Invalid motor encoder value.
(Head movement stopped.)
Check the connection between the
head motor and control board inside
the head and restart production.
Then, check the situation of the
error occurred and error message,
and contact PFSC.
1709
Current exceeding the
specified value has flown
during head movement.
(Abnormal voltage of current
was supplied to the head
motor.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1710
Positional deviation with
power ON or integrated
current is beyond the
specified value.
(Head movement stopped
due to overload.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1711
2-1-4-56
NPM-TT2 EJM1EE-MB-02T-02
Timeout Error
Command processing
error
Over Current Anomaly(R)
Encoder Disconnect
Anomaly(R)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Invalid motor encoder value.
(Head movement stopped.)
Check the connection between the
head motor and control board inside
the head and restart production.
Then, check the situation of the
error occurred and error message,
and contact PFSC.
1712
Current exceeding the
specified value has flown
during head movement.
(Abnormal voltage of current
was supplied to the head
motor.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1713
Communication error
occurred between the driver
and host. Cable between the
head motor and driver may
be broken.
(Error occurred in command
processing.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1714
No response from the head
or feeder cart^ etc.
(Communication timeout
error occurred.)
Clean the drawer connectors for
connecting head and feeder cart,
and check the wiring to be
connected to them. If the error
persists, contact PFSC.
1715
2-1-4-57
