NPM- TT2 EJM1EE-MB-02 T-02 Parts Re cognition Error Error Messag e Troubleshooting 2-1-3 Single stop errors 41 Error Code Error Message Cause Inspection and Solution The contrast (difference in brightness) between the co…

NPM-TT2 EJM1EE-MB-02T-02

Parts Recognition Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

The degree of

perpendicularity of the

component outer edge

(molding) or lead array is

incorrect.Opposite sides of a

square chip are not parallel

or the side angles of a lead

array component are not

perpendicular.The lead array

of a miniature transistor or

other component is not

straight or parallel because

the leads are not aligned in

the length direction.

(Recognition error -

Component outer edge angle

(parallelism or

perpendicularity)

Take any of the following measures:

1) Check the condition of the

electrodes.If the lead length of the

lead array components differs

partly, register the lead length

correctly.

2) Check the component pickup

position and pickup

condition.Make sure the

component pickup position is not

placed at the center and the

component is not likely to be in the

slanted pickup posture.

43043

2-1-3-80

NPM-TT2 EJM1EE-MB-02T-02

Parts Recognition Error

Error

Messag

Troubleshooting

2-1-3

Single stop errors 41

Error Code

Error Message

Cause Inspection and Solution

The contrast (difference in

brightness) between the

component and background

is not good.Brightness of the

component and the

background of the detection

area are not different enough

to distinguish the

two.Nothing suggestive of a

component was found in the

detection area.

(Recognition error - Image

contrast status)

Take any of the following measures:

1) Check the image status of the

component.If the color level of the

image is not separated on the

image as follows, check the setting

of lamp value or component size

data (outer shape size).<In

component recognition>Shadow

light: Component background in

white/Components in

blackReflective light: Component

background in black/Component

electrode in white

2) Check that the target component

appears in the window.If the target

component does not appear in the

window, check the pickup position

and the component size data

(external size).

43045

2-1-3-81

NPM-TT2 EJM1EE-MB-02T-02

Parts Recognition Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

The state which is measured

by 3D sensor is abnormal.･

Lead float and ball

collapse.The level state of

parts all is abnormal.

(Recognition error Electrode

Part or Parts All Height

(Float) Abnormal)

1)Please confirm the variability state

and absorption state of object

parts height .

2)On the situation that the

recognition of Ans47(30~36) is

error,It is judged that part of

electrode is float.Recognition

Option:Please confirm the set of

float permission.On the situation

that the recognition of Ans47(37) is

error,It is judged that all the

levelness of parts is

abnormal.Please confirm surface

adsorption state(whether the

adsorption state depended with

projection etc exists) of parts.

43046

2-1-3-82
