NPM- TT2 EJM1EE-MB-02 T-02 L-Camera Board External 5V Fuse Disconne ction L-Camera Board Light 24V Fuse Disconne ction L-Camera Board Temper ature Erro r H-Camera Board PCB Warp age Sensor F use Disco nnection H-Camer a …
NPM-TT2 EJM1EE-MB-02T-02
H-Camera Board External
5V Fuse Disconnection
H-Camera Board Light
24V Fuse Disconnection
H-Camera Light Control
Board Temperature Error
ILK Board Temperature
Error
ILK Board Voltage Error
Error
Messag
e
Troubleshooting
2-1-2
Self-diagnosis errors 13
Error Code
Error Message
Cause Inspection and Solution
Voltage at the ILK board has
dropped abnormally.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40075
CPU temperature at the ILK
board has exceeded the
setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40076
CPU temperature at the head
camera light control board
has exceeded the setting
value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40077
24V fuse of the head camera
light control board has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40078
External 5V fuse of the head
camera light control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40079
2-1-2-25
NPM-TT2 EJM1EE-MB-02T-02
L-Camera Board External
5V Fuse Disconnection
L-Camera Board Light 24V
Fuse Disconnection
L-Camera Board
Temperature Error
H-Camera Board PCB
Warpage Sensor Fuse
Disconnection
H-Camera Board External
24V Fuse Disconnection
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
External 24V fuse of the
head camera light control
board has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40080
PCB warp sensor fuse of the
head camera light control
board has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40081
CPU temperature at the line
camera light control board
has exceeded the setting
value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40082
24V fuse of the line camera
light control board has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40083
External 5V fuse of the line
camera light control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40084
2-1-2-26
NPM-TT2 EJM1EE-MB-02T-02
Tray A Control Board Fuse
Disconnection
Tray A Control Board
Temperature Error
Tray A Control Board
Voltage Error
L-Camera Board External
24V Fuse Disconnection
Error
Messag
e
Troubleshooting
2-1-2
Self-diagnosis errors 14
Error Code
Error Message
Cause Inspection and Solution
External 24V fuse of the line
camera light control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40085
Voltage at the tray control
board has dropped
abnormally.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40086
CPU temperature at the tray
control board has exceeded
the setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40087
Fuse of the tray control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40088
2-1-2-27
