NPM- TT2 EJM1EE-MB-02 T-02 Check error before axis action PartsD etectAfterMounting( VLCOutputData ou t of validRangeErr) Solutions to errors Error Code Error Message Cause Inspection and Solution Return the output value…
NPM-TT2 EJM1EE-MB-02T-02
Nozzle Change Error
EMG state detect
Invalid Mounted Points
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 60
Error Code
Error Message
Cause Inspection and Solution
System may be at fault.
(Mismatch occurred in
mounting finished points.)
Contact PFSC.
2223
Any of the following causes
is likely:
1) Emergency stop switch
has been pressed.
2) Safety cover is open.
3) Opening sensor detected.
(Emergency stop status
detected.)
Eliminate the cause of emergency
stop and restart production.
2224
Any of the following causes
is likely:
1) Improper shutter action at
nozzle changer
2) Improper cylinder action
3) Deformed or bent nozzle
(Nozzle change error
occurred when measure the
cart height .)
Take measures shown with the
same number as that of the cause.
1) Choose [Machine]-[Adjust]-
[Head]-[Nozzle exchange] and
open/close the nozzle changer.
Check for proper movement. If
stopped or caught on the way,
perform cleaning.
2) Replace the cylinder.
3) Replace the nozzle.
2225
2-1-4-118
NPM-TT2 EJM1EE-MB-02T-02
Check error before axis
action
PartsDetectAfterMounting(
VLCOutputData out of
validRangeErr)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Return the output value
which exceeds allowable
range from VLC unit.
(Error occurred in parts
detect after mounting.)
1. Please confirm that there are no
parts dropped on the PCB.2. Please
confirm that there is no dust(Parts
etc.) on the setting side of nozzle
holder set in nozzle changer.3.
Please confirm there is no dust
adhered to VLC unit.4. If it can't be
solved by above 1,2,3, please
calibrate the VLC unit.
2226
According to the soft
process^ move to incorrect
position.
(Error has been detected in
the check before axis action.)
Please start the production again
after confirming the production PCB.
If the error persists, contact PFSC.
2227
2-1-4-119
NPM-TT2 EJM1EE-MB-02T-02
2-1-4-120
