NPM- TT2 EJM1EE-MB-02 T-02 F Proc. Eject detection error Timer safety relay abnormal Rear moveable cover open or close action incomplete error Front moveable cover open or close action incomplete error Error Messag e Tro…

NPM-TT2 EJM1EE-MB-02T-02

Rear cart unconnected

error

Front cart unconnected

error

Nzl Direction Setting Error

Tray Pos Offset Measure

Err

LNB nzl use interlock error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

There is nozzle which has

been judged as unavailable

nozzle in LNB in nozzle

changer.

(Single stop error occurred.)

Please change the error nozzle to a

normal nozzle.

44027

Failed in tray position offset

measure.

(Single stop error occurred.)

Please execute tray pickup position1

and pickup position2 action in the

calibration 4th process.

44028

Changer nozzle direction

setting is wrong.

(Single stop error occurred.)

Please set the changer nozzle by

correct direction.

44029

Because the Front cart isn't

connected or the Front

moveable cover is opening^

XY action can't be executed.

(Interlock occurred.)

Please connect the Front cart or

close the Front moveable cover.

44031

Because the Rear cart isn't

connected or the Rear

moveable cover is opening^

XY action can't be executed.

(Interlock occurred.)

Please connect the Rear cart or

close the Rear moveable cover.

44032

2-1-3-100

NPM-TT2 EJM1EE-MB-02T-02

F Proc. Eject detection

error

Timer safety relay

abnormal

Rear moveable cover

open or close action

incomplete error

Front moveable cover

open or close action

incomplete error

Error

Messag

Troubleshooting

2-1-3

Single stop errors 51

Error Code

Error Message

Cause Inspection and Solution

Because the Front moveable

cover open or close action is

incomplete^ XY action can't

be executed.

(Interlock occurred.)

Please confirm if the Front

moveable cover action is executed

correctly in Arrange-PartsPrepare-

Feeder screen.

44033

Because the Rear moveable

cover open or close action is

incomplete^ XY action can't

be executed.

(Interlock occurred.)

Please confirm if the Rear moveable

cover action is executed correctly in

Arrange-PartsPrepare-Feeder

screen.

44034

Because the timer safety

relay is time out.

(Interlock occurred.)

Please connect the cart or close the

moveable cover.

44035

In the setting of

communication between

MC^ because the PCB is

carried in before the

detection of the ejection

signal from the pre process

equipment^ error occurred.

(The ejection signal isn't

detected from the pre

process equipment.)

Please take any of the following

measures:

1)Please confirm the setting of

communication between MC.

2)Please confirm the ejection signal

output setting of pre process

equipment.

44036

2-1-3-101

NPM-TT2 EJM1EE-MB-02T-02

Cover Open

(Rear Side Safety switch

this side)

Cover Open

(Front Side Safety switch

this side)

Error

Messag

Solutions to errors

Troubleshooting

2-1-4

Emergency stop errors 1

Error Code

Error Message

Cause Inspection and Solution

Safety cover is open.

(Interlock occurred.)

Take measures in the following

order.

1) Close the safety cover if opened.

2) If the error persists even after the

safety cover is closed, the safety

switch may be at fault.Contact

PFSC.

1302

Safety cover is open.

(Interlock occurred.)

Take measures in the following

order.

1) Close the safety cover if opened.

2) If the error persists even after the

safety cover is closed, the safety

switch may be at fault.Contact

PFSC.

1303

2-1-4-1
