NPM- TT2 EJM1EE-MB-02 T-02 Splicing Length Sto p Cover Open PCB Position Error Solutions to errors Error Code Error Message Cause Inspection and Solution PCB is removed or is not placed at the cor rect position. (Single …
NPM-TT2 EJM1EE-MB-02T-02
Conveyor Width Adj. Err
PCB Transfer Error
PCB Recognition Error
Error
Messag
e
Troubleshooting
2-1-3
Single stop errors 3
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Recognition mark is out of
camera's view.
2) Recognition error
occurred due to dirt on PCB.
3) PCB recognition
coordinates are incorrect.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Using the inching function, move
the camera to the recognition mark
position and press the Re-
recognize button.
2) After cleaning the recognition
camera and PCB, press the Re-
recognize button. If the recognition
error occurs again, move the
camera to the recognition mark
position with the Pass button or
inching function and press the
Manual set button. [Pass]: Pass
the PCB.[Manual set]: Save the
inching amount as the offset.
3) Choose [Production data] -
[Correct] - [PCB] - [PCB recog.]
and enter the correct PCB
recognition coordinates.
40313
PCB failed to be transferred
properly.
(Single stop error occurred.)
Check inside the machine and
remove the PCB.
40314
Width adjustment is disabled
because of the PCB on the
conveyor.
(Single stop error occurred.)
Remove the PCB.
40315
2-1-3-5
NPM-TT2 EJM1EE-MB-02T-02
Splicing Length Stop
Cover Open
PCB Position Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
PCB is removed or is not
placed at the correct position.
(Single stop error occurred.)
1) Set the PCB in position.
2) If the PCB is removed, press the
[PCB Remove] button.
40316
Safety cover is open.
(Single stop error occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
40317
Tape is getting low.
(Single stop error occurred.)
Perform tape splicing.
40318
2-1-3-6
NPM-TT2 EJM1EE-MB-02T-02
Pick-up Height Measure
Error
No Splicing Check Warn.
No Splicing Check
Error
Messag
e
Troubleshooting
2-1-3
Single stop errors 4
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Splicing work not
performed.
2) Spliced part of the tape
has been recognized by
mistake.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Perform splicing work properly.
Make sure the reel is properly
installed and check the joint
detection sensor. Then, press the
Supply Complete button.
2) Cancel the joint detection.
40319
Any of the following causes
is likely:
1) Splicing work not
performed.
2) Spliced part of the tape
has been recognized by
mistake.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Perform splicing work properly.
Make sure the reel is properly
installed and check the joint
detection sensor. Then, press the
Supply Complete button.
2) Cancel the joint detection.
40320
Feeder or tray not set from
which the component is
picked up.
(Single stop error occurred.)
Make sure that the feeder or pallet is
properly set and the nozzle is
properly set on the head.
40321
