NPM-TT2 EJM1EE-MB-02T-02
Software Overrun Limit
Axis Motion Incomplete
Dispense error on the rail
Power On Init Error
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 13
Error Code
Error Message
Cause Inspection and Solution
Failed to initialize data at
power ON.
(Initialization error occurred
at power ON)
Turn OFF power once and restart
the machine.
1507
Invalid data set in the
coordinates to be dispensed.
(Dispense error on the rail
occurred.)
Check the dispensing position on
the PC board of the dispense point
data or priming shot data, and
correct if necessary.
1508
Error occurred in the servo
driver.
(Axis error occurred.)
1) Check the error code and take
appropriate action according to the
servo driver error code list in the
Maintenance Manual.
2) Turn OFF the machine and turn it
back ON to restart the machine.
1511
Invalid data set in the
software parameter for X-
axis movement.
(X-axis movement software
parameter error occurred.)
Check the software parameter on
the error window and modify the
production data or machine
parameter if necessary.Contact
PFSC.
1512
2-1-4-24
NPM-TT2 EJM1EE-MB-02T-02
Tape Float
Driver Software Interlock
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Servo driver of the target axis
is at fault.
(Driver software interlock
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1513
The tape cover sensor is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensors 1 to 4 of
the table are OFF when the light
from the emitter is blocked and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1514
2-1-4-25
NPM-TT2 EJM1EE-MB-02T-02
Motor Number Error
Reset Process Error
Servo Process Error
Motor Object Not Exist
Nozzle shaft drop
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 14
Error Code
Error Message
Cause Inspection and Solution
Nozzle shaft may be locked
at the lowered position.
(Nozzle shaft drop error
occurred.)
Do not move the head in X/Y
direction. Raise the nozzle shaft by
hand.
1515
Servo driver of the target axis
is at fault.
(No motor object.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1521
Servo driver of the target axis
is at fault.
(Servo process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1522
Servo driver of the target axis
is at fault.
(Reset process error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1523
Servo driver of the target axis
is at fault.
(Motor number error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1524
