NPM-TT2 EJM1EE-MB-02T-02
Tape cover detection1
(Rear)
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 10
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 1 is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the cover tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 1 of the
table is OFF when the light from
the emitter is blocked and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1335
2-1-4-18
NPM-TT2 EJM1EE-MB-02T-02
No Feeder cover
(Rear)
No Feeder cover
(Front)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Feeder cover not attached.
(Interlock occurred.)
Take measures in the following
order.
1) Attach the feeder cover.
2) If the error persists even after the
feeder cover is attached, the
connection with the feeder cover
may not be detected.Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the connection
of feeder cover.
1336
Feeder cover not attached.
(Interlock occurred.)
Take measures in the following
order.
1) Attach the feeder cover.
2) If the error persists even after the
feeder cover is attached, the
connection with the feeder cover
may not be detected. Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the connection
of the feeder cover.
1337
2-1-4-19
NPM-TT2 EJM1EE-MB-02T-02
Support Plate Position
Output Error
(Right)
Support Plate Position
Output Error
(Left)
Changeover Cart
Unconnected
(Rear)
Changeover Cart
Unconnected
(Front)
Error
Messag
e
Troubleshooting
2-1-4
Emergency stop errors 11
Error Code
Error Message
Cause Inspection and Solution
Feeder cart connector not
connected.
(Interlock occurred.)
Connect the feeder cart
again.Choose [Machine] - [Adjust] -
[All] - [Input confirm] and check the
connection of feeder cart. If any
problem is found, contact PFSC.
1339
Feeder cart connector not
connected.
(Interlock occurred.)
Connect the feeder cart
again.Choose [Machine] - [Adjust] -
[All] - [Input confirm] and check the
connection of feeder cart. If any
problem is found, contact PFSC.
1340
Support plate cannot be
raised since the head is
within the mounting area.
(Interlock occurred.)
Move the head away from the
mounting area.
1341
Support plate cannot be
raised since the head is
within the mounting area.
(Interlock occurred.)
Move the head away from the
mounting area.
1342
2-1-4-20
