Module Technical Data Technical Data 108 JEDEC Tray Feeder Dimensions -- approx. 330 mm x 150 mm x 230 mm Max. load. weight -- 2.7 kg (150 g each with 18 racks) Pneumatic 4.1 bar to 5.5 bar 5.2 bar to 9 bar Compressed ai…
Module Technical Data
Technical Data
JEDEC Tray Feeder 107
3
3 Module Technical Data
Module Technical Data
3.1
3.1 Technical Data
Technical Data
1 JEDEC tray feeder
2 Fixed table
SIPLACE JTF-S [166670] SIPLACE JTF-M [166671]
Width 162 mm 177 mm
Height 587 mm 587 mm
Storage capacity
Waffle pack tray, thin JEDEC waffle pack tray 30 JEDEC waffle pack tray 18
Waffle pack tray, thick JEDEC waffle pack tray 20 JEDEC waffle pack tray 14
Weight ~ 25.7 Kg (50 lbs.) – depends on application
Waffle pack tray changeover
times
< 5 seconds (depending on ap-
plication)
--
Rack n after n+1 3.5 seconds
Rack 1 after 18 -- 10 seconds
Rack 18 after 1 -- 8.9 seconds
Cassette
Module Technical Data
Technical Data
108 JEDEC Tray Feeder
Dimensions -- approx. 330 mm x 150 mm x 230
mm
Max. load. weight -- 2.7 kg
(150 g each with 18 racks)
Pneumatic 4.1 bar to 5.5 bar 5.2 bar to 9 bar
Compressed air consumption < 28.3 NL/min. < 28.3 NL/min.
JEDEC waffle pack tray specifications
JEDEC standard 95-1 & IEC 60286-5
Waffle pack tray width 135.9 mm (+0.25 mm / - 0.13 mm)
Waffle pack tray length 322.6 mm (+0.25 mm / - 0.13 mm)
Thickness
Waffle pack tray, thin 7.62 mm (+/- 0.2mm)
Waffle pack tray, thick 12.19 mm (+/- 0.2 mm)
Waffle pack tray material
Standard Plastic with glass
Optional Aluminum
Levelness of waffle pack tray 0.8 mm across whole waffle pack tray
SIPLACE JTF-S [166670] SIPLACE JTF-M [166671]
Module Technical Data
3.2.1 SIPLACE JTF-M Overview of the Modules
JEDEC Tray Feeder 109
3.2
3.2 Overview of the Modules
Overview of the Modules
3.2.1
3.2.1 SIPLACE JTF-M
SIPLACE JTF-M
1. Pick position
2. Tray clamp
3. Conveyor
4. Magazine
5. Feeder base
1. Button panel
2. 4 ears
3. Handle
4. Door (open)
5. Magazines
1. Forward slow down sensor
2. Return slow down sensor
