Setting up and Commissioning
Installation 4.4.3 Inserting the JEDEC Tray Feeder
140 JEDEC Tray Feeder
► Fix the hose with cable ties (1).
CAUTION
Hand guard
If you remove the JEDEC tray feeder, replace it by a dummy feeder.
Setting up and Commissioning
4.4.4 Final Work: Installation
JEDEC Tray Feeder 141
4.4.4
4.4.4 Final Work:
Final Work:
► Switch on the machine and make the necessary settings in the software.
NOTICE
Dummyfeeder
In case you remove the JEDEC Tray Feeder, you have to replace it with a dummyfeeder X8
[03012733-xx].
Setting up and Commissioning
Installation 4.4.4 Final Work:
142 JEDEC Tray Feeder
