Introduction Module Description 1.1.2 EU Declaration of Conformity 92 JEDEC Tray Feeder 1.1.2 1 . 1 . 2 E U D e c la r a t io n o f C o n f o r m it y EU Declaration of Conformity The product/device described below confo…

Introduction

1.1.1 Typeplate and Serial Number Module Description

JEDEC Tray Feeder 91

1 Introduction

Introduction

This manual provides technical information and describes how to operate the JEDEC tray feeder in the

SIPLACE® family.

1.1

1.1 Module Description

Module Description

The JEDEC tray feeder is an automatic and fast changer for standard JEDEC waffle pack trays. On

SIPLACE X-Series S machines, a JEDEC tray feeder can be installed on a fixed changeover table in-

stead of a component trolley.

The JEDEC tray feeder occupies a fixed area of tracks on the fixed changeover table. The JEDEC tray

feeder is available in two versions:

▪ SIPLACE JTF-S

▪ SIPLACE JTF-M

SIPLACE JTF-S

The SIPLACE JTF-S stores a stack of up to 30 thin or 20 thick JEDEC waffle pack trays and supplies

them in succession. The placement machine can be supplied with one component type at constant

changeover time.

SIPLACE JTF-M

Depending on the magazine type, the SIPLACE JTF-M stores up to 18 thin or 14 thick JEDEC waffle

pack tray magazines in an exchangeable cassette and supplies them as required.

The placement machine can therefore be supplied with different component types at variable changeo-

ver times.

1.1.1

1.1.1 Typeplate and Serial Number

Typeplate and Serial Number

The feeder modules have a typeplate on their sides, which specifies the type, material and serial num-

ber.

▪ Type: SIPLACE JTF-M

▪ Material No./Material-Nr.: 166671

▪ Serial No.:0001

Introduction

Module Description 1.1.2 EU Declaration of Conformity

92 JEDEC Tray Feeder

1.1.2

1.1.2 EU Declaration of Conformity

EU Declaration of Conformity

The product/device described below conforms to the regulations and standards listed in the EU Decla-

ration of Conformity provided.

Manufacturer:

ASM Assembly Systems GmbH & Co. KG

Rupert-Mayer-Strasse 44

81379 Munich

Germany

1.1.3

1.1.3 Correct Usage

Correct Usage

The product may only be used for the application cases described in the catalogues and technical spec-

ifications i.e. for placement of SMD components and only in connection with the third party devices and

components recommended or approved by SIPLACE.

Any other use is deemed to be incorrect and not as prescribed.

If the product is not used as prescribed, SIPLACE will accept no liability for any damage that may occur

and will not guarantee that the components will work properly and without problems.

Prescribed or correct usage includes the observance of all the instructions in the user manual.

The proper and safe operation of the product requires correct transportation, storage, installation and

assembly, plus careful, accurate utilization and servicing.

▪ Attachment of typeplate to the

SIPLACE JTF-S, SIPLACE JTF-M (1).

Model JEDEC tray stack feeder

Type SIPLACE JTF-S

Item no.: 166670-xx

Model JEDEC tray stack feeder

Type SIPLACE JTF-M

Item no.: 166671-xx

Introduction

1.1.4 Incorrect Usage Important Notes about the Operating Manual

JEDEC Tray Feeder 93

1.1.4

1.1.4 Incorrect Usage

Incorrect Usage

Failure to use the product as prescribed can result in both danger to life and limb and material damage.

For this reason, non-prescribed usage is prohibited. If the product is not used as prescribed, ASM As-

sembly Systems GmbH & Co. KG will not accept liability for any damage that may occur and will not

guarantee that the components will work properly and without problems.

Non-prescribed use of the module includes the following examples:

▪ Operation of the module with safety equipment deactivated or removed.

▪ Placement of components that do not meet the permitted specification.

▪ Use of unauthorized accessories and additional modules.

▪ Use of the module by unqualified personnel.

1.1.5

1.1.5 Noise Emissions

Noise Emissions

1.1.6

1.1.6 Environmentally-Friendly Disposal of Materials and Components

Environmentally-Friendly Disposal of Materials and Components

SIPLACE products are manufactured using only materials and parts that can be easily separated and

disposed of in an environmentally-friendly way.

1.1.7

1.1.7 Electromagnetic Compatibility (EMC)

Electromagnetic Compatibility (EMC)

All SIPLACE products are designed and tested for professional use in industrial applications. Electro-

magnetic compatibility in terms of the emission of interference cannot be guaranteed in any other envi-

ronment.

1.1.8

1.1.8 Use of Original SIPLACE Accessories and Spare Parts

Use of Original SIPLACE Accessories and Spare Parts

Only use original spare parts and authorized accessories. The use of other parts will affect safety and

will invalidate the liability for any consequential damage.

1.2

1.2 Important Notes about the Operating Manual

Important Notes about the Operating Manual

1.2.1

1.2.1 Contents and Filing of this Manual

Contents and Filing of this Manual

This user manual contains basic information that must be observed when setting up, operating and main-

taining the machine. The service engineers, qualified staff, operators and users must therefore read it

before commencing installation and commissioning. The instructions must be kept permanently acces-

sible wherever the machine is used.

In addition, the user must ensure that the employees have fully understood the contents of the user man-

ual.

Maximum noise level 75 dB (A)

NOTICE

Observe the applicable regulations

The company operating the system has sole responsibility for the proper, environmentally-

friendly disposal of machines, working materials, consumables and wear parts.

► Please observe your national statutory provisions for waste disposal and environmental

protection.
