3 SAFETY FEATURES
3.1 OVERVIEW
TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019 21
3
SAFETY FEATURES
3.1 OVERVIEW
The printer incorporates various safety features that provide a safe operating environment for the
operators/maintainers using:
●
Safety interlocks ensure that potentially hazardous machine operations can only be performed
when the machine is in a safe condition
●
Safety labels to inform the user of areas where danger or residual danger may exist
All safety circuits have been designed to meet the safety requirements as outlined in the machines’
CE Declaration of Conformity. The circuits check for welded contacts before resetting. Additional
safety is achieved by duplication of the power contactors to provide redundancy.
3.1.1 Mains Supply
Where incoming hazardous supply voltages are present, protection is afforded by controlling
access to the enclosures that house the supply. The enclosures require tools to gain access to the
inside and must only be opened by suitably qualified personnel.
The mains isolator switch disconnects the facility mains supply to the power supply enclosure.
Mains supply still exists in the printer, up to the mains isolator switch.
Hazard warning labels are placed on the outside of enclosures where dangerous voltage
(100V-240V a.c 50-60Hz) terminations are present within.
3.1.2 Safety Notices
Safety notices in the form of PROHIBITION, WARNING, CAUTION and MANDATORY labels are
placed on the printing machine and notices are posted throughout the associated documentation to
alert the operator/maintainer to possible hazards which may cause physical injury or equipment
damage.
The following label illustrated below, may be fitted to the printer, this signifies that the user should
refer to the relevant section of the Technical Reference Manual before attempting to carry out work
on the equipment.
3.1.2.1 Prohibition Notices
Prohibition notices draw the attention of users/maintainers to prohibiting behaviour likely to cause a
risk to health or safety. The following table displays the prohibition labels affixed to printer and dis-
played in the machine documentation.
Symbol Definition
PROHIBITION
MACHINE COVERS. IN ORDER TO PROTECT PERSONNEL AND TO PRE-
VENT DAMAGE TO THE MACHINE, COVERS ARE FITTED TO THE MACHINE
FRAME. THESE PANELS MUST ONLY BE REMOVED BY SUITABLY QUALI-
FIED PERSONNEL.
3 SAFETY FEATURES
3.1 OVERVIEW
22 TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019
3.1.2.2 Warning Notices
Warning notices draw the attention of users/maintainers to a potentially hazardous situation which,
if not avoided, could result in death or serious injury. The following table displays the warning labels
affixed to printer and/or displayed in the machine documentation.
Symbol Definition
WARNING
MOVING PARTS. MOVING PARTS ARE PRESENT IN THE VICINITY OF THIS
WARNING LABEL, THESE PARTS HAVE THE POTENTIAL TO CAUSE IN-
JURY.
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING
IN THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS
ON THE FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
WARNING
FLAMMABLE. FLAMMABLE SUBSTANCES ARE PRESENT. KEEP AWAY
FROM HEAT, SOURCES OF IGNITION AND STATIC DISCHARGES. USE IN A
WELL VENTILATED AREA.
WARNING
LETHAL VOLTAGE. DANGEROUS VOLTAGES EXIST IN THIS EQUIPMENT.
ENSURE ALL ELECTRONIC COVERS AND MAIN MACHINE COVERS ARE
FITTED BEFORE OPERATING THIS EQUIPMENT.
WARNING
HOT SURFACES. THE SURFACE OF THIS COMPONENT OR SURROUND
AREA MAY BECOME HOT DURING PROLONGED OPERATION. CARE TO BE
TAKEN WHEN WORKING IN THE VICINITY OF THIS COMPONENT.
WARNING
COMPRESSED AIR. COMPRESSED AIR SHOULD NEVER IMPINGE UPON
THE BODY, PORTS, PIPES, ETC MUST NEVER BE BLOCKED BY HAND. BE-
FORE CONNECTING OR DISCONNECTING ANY PNEUMATIC COMPON-
ENTS, ENSURE THE COMPRESSED AIR SUPPLY HAS BEEN DISSIPATED
AND DISCONNECTED FROM THE MACHINE.
WARNING
E STOP CIRCUIT. THE E STOP ONLY ISOLATES THE DC SUPPLIES TO THE
MOTORS. LETHAL VOLTAGES ARE STILL PRESENT WITHIN THE MACHINE
AFTER THE E STOP HAS BEEN ACTIVATED.
WARNING
HARMFUL SUBSTANCES. CLEANING WIPES AND CLEANING SOLUTIONS
MAY CONTAIN SUBSTANCES HAZARDOUS TO HEALTH. WHEN USING
CLEANING WIPES AND CLEANING SOLUTIONS THE MANUFACTURER'S
SAFETY DATA SHEETS MUST BE STRICTLY ADHERED TO.
WARNING
MACHINE LIFTING. TO PREVENT SERIOUS INJURY TO PERSONNEL, DUR-
ING LIFTING AND TRANSPORTATION OPERATIONS, ENSURE THE MA-
CHINE IS LIFTED AND TRANSPORTED IN ACCORDANCE WITH INSTRUC-
TIONS DETAILED IN THIS SECTION.
3 SAFETY FEATURES
3.1 OVERVIEW
TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019 23
Symbol Definition
WARNING
SOLVENT SPRAY. THE UNDERSCREEN CLEANER SPRAYS A FINE JET OF
SOLVENT SOLUTION ON TO THE CLEANER. APPROVED PROTECTIVE
CLOTHING SHOULD BE WORN.
WARNING
HEAVY OBJECT. EXTREME CAUTION SHOULD BE EXERCISED WHEN
MANUALLY HANDLING HEAVY ITEMS INTO OR OUT OF THE MACHINE.
3.1.2.3 Caution Notices
Caution notices draw the attention of users/maintainers to a potentially hazardous situation which,
if not avoided may result in minor or moderate injury. The following table displays the caution labels
affixed to the printer and/or displayed in the machine documentation.
Symbol Definition
CAUTION
RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST COMPLY WITH
LOCAL ENVIRONMENTAL GUIDELINES. ASM RECOMMENDED USING
SOLVENTS THAT ARE ENVIRONMENTALLY FRIENDLY, IE CFC FREE AND
WATER BASED. SOLVENTS USED MUST HAVE FAST EVAPORATION
RATES AND FLASHPOINT SPECIFICATIONS GREATER THAN 39°C.
CAUTION
SOLDER PASTE AND SOLVENTS. WHEN USING OR HANDLING ANY
SOLDER PASTE OR SOLVENT FORMULATION THE MANUFACTURERS'
SAFETY DATA SHEETS MUST BE STRICTLY ADHERED TO.
CAUTION
SOLVENT SOLUTION. DO NOT MIX SOLVENT SOLUTIONS. FLUSH THE
SOLVENT TANK THOROUGHLY WHEN CHANGING TO A DIFFERENT
SOLVENT SOLUTION.
CAUTION
ANTI-STATIC HANDLING. STANDARD PRECAUTIONS MUST BE ADHERED
TO WHEN HANDLING ELECTRONIC CARDS AND CONFIGURING AND IN-
SERTING INTO THE ENCLOSURES.
CAUTION
RADIATION. RISK OF INJURY TO THE EYES DUE TO LASER LIGHT BEING
PRESENT IN THE VICINITY OF THE LABEL. DO NOT LOOK AT THE LIGHT
SOURCE OR REFLECTIONS FROM A SURFACE.
CAUTION
EQUIPMENT SERVICING. THE LASER DOES NOT CONTAIN USER SER-
VICEABLE PARTS. OPENING THE UNIT COULD CAUSE MISALIGNMENT OF
THE LASER, THIS MAY MAKE THE EQUIPMENT DANGEROUS TO OPER-
ATE.
CAUTION
LASER CONTROLS AND ADJUSTMENTS. USE OF CONTROLS OR ADJUST-
MENTS OR PERFORMANCEE OF PROCEDURES OTHER THAN THOSE SPE-
CIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
