3 SAFETY FEATURES 3.1 OVERVIEW TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019 23 Symbol Definition WARNING SOLVENT SPRAY. THE UNDERSCREEN CLEANER SPRAYS A FINE JET OF SOLVENT SOLUTION ON TO THE CLEANER. APPROVED PROTE…
3 SAFETY FEATURES
3.1 OVERVIEW
22 TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019
3.1.2.2 Warning Notices
Warning notices draw the attention of users/maintainers to a potentially hazardous situation which,
if not avoided, could result in death or serious injury. The following table displays the warning labels
affixed to printer and/or displayed in the machine documentation.
Symbol Definition
WARNING
MOVING PARTS. MOVING PARTS ARE PRESENT IN THE VICINITY OF THIS
WARNING LABEL, THESE PARTS HAVE THE POTENTIAL TO CAUSE IN-
JURY.
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING
IN THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS
ON THE FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
WARNING
FLAMMABLE. FLAMMABLE SUBSTANCES ARE PRESENT. KEEP AWAY
FROM HEAT, SOURCES OF IGNITION AND STATIC DISCHARGES. USE IN A
WELL VENTILATED AREA.
WARNING
LETHAL VOLTAGE. DANGEROUS VOLTAGES EXIST IN THIS EQUIPMENT.
ENSURE ALL ELECTRONIC COVERS AND MAIN MACHINE COVERS ARE
FITTED BEFORE OPERATING THIS EQUIPMENT.
WARNING
HOT SURFACES. THE SURFACE OF THIS COMPONENT OR SURROUND
AREA MAY BECOME HOT DURING PROLONGED OPERATION. CARE TO BE
TAKEN WHEN WORKING IN THE VICINITY OF THIS COMPONENT.
WARNING
COMPRESSED AIR. COMPRESSED AIR SHOULD NEVER IMPINGE UPON
THE BODY, PORTS, PIPES, ETC MUST NEVER BE BLOCKED BY HAND. BE-
FORE CONNECTING OR DISCONNECTING ANY PNEUMATIC COMPON-
ENTS, ENSURE THE COMPRESSED AIR SUPPLY HAS BEEN DISSIPATED
AND DISCONNECTED FROM THE MACHINE.
WARNING
E STOP CIRCUIT. THE E STOP ONLY ISOLATES THE DC SUPPLIES TO THE
MOTORS. LETHAL VOLTAGES ARE STILL PRESENT WITHIN THE MACHINE
AFTER THE E STOP HAS BEEN ACTIVATED.
WARNING
HARMFUL SUBSTANCES. CLEANING WIPES AND CLEANING SOLUTIONS
MAY CONTAIN SUBSTANCES HAZARDOUS TO HEALTH. WHEN USING
CLEANING WIPES AND CLEANING SOLUTIONS THE MANUFACTURER'S
SAFETY DATA SHEETS MUST BE STRICTLY ADHERED TO.
WARNING
MACHINE LIFTING. TO PREVENT SERIOUS INJURY TO PERSONNEL, DUR-
ING LIFTING AND TRANSPORTATION OPERATIONS, ENSURE THE MA-
CHINE IS LIFTED AND TRANSPORTED IN ACCORDANCE WITH INSTRUC-
TIONS DETAILED IN THIS SECTION.
3 SAFETY FEATURES
3.1 OVERVIEW
TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019 23
Symbol Definition
WARNING
SOLVENT SPRAY. THE UNDERSCREEN CLEANER SPRAYS A FINE JET OF
SOLVENT SOLUTION ON TO THE CLEANER. APPROVED PROTECTIVE
CLOTHING SHOULD BE WORN.
WARNING
HEAVY OBJECT. EXTREME CAUTION SHOULD BE EXERCISED WHEN
MANUALLY HANDLING HEAVY ITEMS INTO OR OUT OF THE MACHINE.
3.1.2.3 Caution Notices
Caution notices draw the attention of users/maintainers to a potentially hazardous situation which,
if not avoided may result in minor or moderate injury. The following table displays the caution labels
affixed to the printer and/or displayed in the machine documentation.
Symbol Definition
CAUTION
RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST COMPLY WITH
LOCAL ENVIRONMENTAL GUIDELINES. ASM RECOMMENDED USING
SOLVENTS THAT ARE ENVIRONMENTALLY FRIENDLY, IE CFC FREE AND
WATER BASED. SOLVENTS USED MUST HAVE FAST EVAPORATION
RATES AND FLASHPOINT SPECIFICATIONS GREATER THAN 39°C.
CAUTION
SOLDER PASTE AND SOLVENTS. WHEN USING OR HANDLING ANY
SOLDER PASTE OR SOLVENT FORMULATION THE MANUFACTURERS'
SAFETY DATA SHEETS MUST BE STRICTLY ADHERED TO.
CAUTION
SOLVENT SOLUTION. DO NOT MIX SOLVENT SOLUTIONS. FLUSH THE
SOLVENT TANK THOROUGHLY WHEN CHANGING TO A DIFFERENT
SOLVENT SOLUTION.
CAUTION
ANTI-STATIC HANDLING. STANDARD PRECAUTIONS MUST BE ADHERED
TO WHEN HANDLING ELECTRONIC CARDS AND CONFIGURING AND IN-
SERTING INTO THE ENCLOSURES.
CAUTION
RADIATION. RISK OF INJURY TO THE EYES DUE TO LASER LIGHT BEING
PRESENT IN THE VICINITY OF THE LABEL. DO NOT LOOK AT THE LIGHT
SOURCE OR REFLECTIONS FROM A SURFACE.
CAUTION
EQUIPMENT SERVICING. THE LASER DOES NOT CONTAIN USER SER-
VICEABLE PARTS. OPENING THE UNIT COULD CAUSE MISALIGNMENT OF
THE LASER, THIS MAY MAKE THE EQUIPMENT DANGEROUS TO OPER-
ATE.
CAUTION
LASER CONTROLS AND ADJUSTMENTS. USE OF CONTROLS OR ADJUST-
MENTS OR PERFORMANCEE OF PROCEDURES OTHER THAN THOSE SPE-
CIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
3 SAFETY FEATURES
3.1 OVERVIEW
24 TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019
3.1.2.4 Mandatory Notices
Mandatory notices draw the attention of users/maintainers to the prescribed behaviour to be ad-
hered whilst engaged in this activity. The following table displays the mandatory labels affixed to
the printer and/or displayed in the machine documentation.
Symbol Definition
MANDATORY
TOXIC SUBSTANCES MAY BE PRESENT. SAFETY GLOVES MUST BE
WORN.
MANDATORY
TOXIC SUBSTANCES MAY BE PRESENT. EYE PROTECTION MUST BE
WORN.
MANDATORY
HEAVY OBJECT. LIFTING OR RESITING MUST BE UNDERTAKEN BY TWO
PEOPLE.
3.1.3 SEMI Labelling
The following table displays the SEMI labelling that may be applied to the printer:
Warning Definition Location
WARNING / DANGER
Pièces mécaniques en mouvement
Retirer les capots ou couvercles
peut entraîner des blessures graves.
Déconnecter et couper l alimentation
électrique avant deffectuer lentretien
de la machine, se référer au
Manuel de Référence Technique.
Moving Mechanical Parts
Removing covers could result
in serious injury
Disconnect and lockout system power
before servicing refer to the
Technical Reference manual
MOVING MECHANICAL PARTS
REMOVING THIS COVER EX-
POSES MOVING MECHANICAL
PARTS THAT HAVE THE PO-
TENTIAL TO CAUSE SERIOUS
INJURY. DISCONNECT AND
LOCK OUT THE SYSTEM
POWER BEFORE REMOVING
THIS COVER. REFER TO THE
LOCKOUT PROCEDURE AT
THE END OF THIS CHAPTER.
GENERAL WARNING
REFER TO THE OPERATOR
MANUAL OR THE FRONT OF
THIS CHAPTER FOR A LIST OF
ALL WARNINGS AND DEFINI-
TIONS.
LEFT HAND
UPPER SIDE
PANEL
