4 COVERS
4.1 PRINTER COVERS
46 TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019
4.1.2.3 Machine Conformity
This label indicates the technical bodies that have given quality assurance approval. The label also
gives the following information.
●
ASM Contact Address
●
Machine Type
●
Machine Serial Number
●
Model Designation
●
Year of Manufacture
The following technical information is used to specify the electrical and pneumatic supplies to the
printer.
●
Voltage Setting
●
Full Load Current Rating
●
Operational Frequency
●
Number of Electrical Phases Required
●
Minimum and Maximum Compressed Air Pressure (in Bar)
●
Earth Equipment Warning
MACHINEMODEL/MASCHINENMODELL
SERIALNo./SERIENNR
SERIES/SERIE
NOMINALVOLTAGE/SPANNUNG:
FULLLOADCURRENT/NENNSTROM:
FREQUENCY/FREQUENZ:
NUMBEROFPHASES/PHASEN:
PRESSURE/DRUNK:
YEAROFMANUFACTURE/JAHRDER
HERSTELLUNG:
DATEOFREFURBISHING
DATUMDERUBERHOLUNG:
MadeinMalaysia
V
A
Hz
50/60
1
5-8
BAR
ASMAssemblySystemsWeymouthLtd.
535YishunIndustrialParkA
ASMTech-ParkBuilding2
Singapore768775
Shortcircuitcurrentrating2KArmssymmetrical,240Vmaximum.
Kurzschlussstrom2KArmssymmetrisch,max.240V.
ASM
Assembly Systems
4 COVERS
4.1 PRINTER COVERS
TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019 47
4.1.2.4 Next Service Due
This label is filled in by the engineer at installation to show when the next service is due. On sub-
sequent service visits the engineer replaces the label.
4 COVERS
4.1 PRINTER COVERS
48 TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019
