MODULE
ERROR
CODE
Symptom and Cause ACTION
Service
Manual
$8351
Nozzle Run-out check error (Run-out>0.120mm) (Head 1)
Run-out of nozzle exceeds 0.12mm.
This has an effect on align check and installment accuracy.
$8352
Nozzle Run-out check error (Run-out>0.120mm) (Head 1)
Run-out of nozzle exceeds 0.12mm.
This has an effect on align check and installment accuracy.
12-3-2
$8353
Nozzle Run-out check error (Run-out>0.120mm) (Head 1)
Run-out of nozzle exceeds 0.12mm.
This has an effect on align check and installment accuracy.
$8701
Aligner result response Error (Head 1)
Fails to receive align results caused by communication error.
$8702
Aligner result response Error (Head 2)
Fails to receive align results caused by communication error.
1-3-1
$8703
Aligner result response Error (Head 3)
Fails to receive align results caused by communication error.
7-3-1
$8711
Aligner Score is too low (Head 1)
Fails to algin during retrying times.
(Either align score of X and Y is less than 80).
$8712
Aligner Score is too low (Head 2)
Fails to algin during retrying times.
(Either align score of X and Y is less than 80).
$8713
Aligner Score is too low (Head 3)
Fails to algin during retrying times.
(Either align score of X and Y is less than 80).
$8731
Aligner component auto inspection error (Head 1)
Fails to find out align information automatically.
12-3-1
$8732
Aligner component auto inspection error (Head 2)
Fails to find out align information automatically.
12-3-3
$8733
Aligner component auto inspection error (Head 3)
Fails to find out align information automatically.
$8741
Please check nozzle in the Head (Head 1)
Nozzle fails to be inserted securely into Head securely.
4-3-2
$8742
Please check nozzle in the Head (Head 2)
Nozzle fails to be inserted securely into Head securely.
4-3-4
Nozzle is to be inserted securely into a Head.
Try again after finding out again Home position by turning on the Aligner DSP Board by pressing and
releasing the <Emergency> switch of operation panel or teaching box.
Check for cable linked conditions between Aligner DSP Board and VME RS-232C I/F Board.
Try again by pressing the Start switch after removing the error condition by pressing the <Reset>
switch of operation panel.
Check that part concerned exists in feeder, and for pickup conditions of part.
Replace a Compliance of Head concerned. (Recommendations)
- 16 -
MODULE
ERROR
CODE
Symptom and Cause ACTION
Service
Manual
$8743
Please check nozzle in the Head (Head 3)
Nozzle fails to be inserted securely into Head securely.
$8821
Aligner Received Unknown Command From Host[02] (Head 1)
Aligner DSP Board is received unknown command from Host(Component Placer).
$8822
Aligner Received Unknown Command From Host[02] (Head 2)
Aligner DSP Board is received unknown command from Host(Component Placer)
1-3-1
$8823
Aligner Received Unknown Command From Host[02] (Head 3)
Aligner DSP Board is received unknown command from Host(Component Placer).
7-3-1
$8831
Aligner Sent Unknown Command From Host[03] (Head 1)
Host(Component Placer) sent unknown command to Aligner DSP Board.
$8832
Aligner Sent Unknown Command From Host[03] (Head 2)
Occurs when Host(Component Placer) transfers unknown command to Aligner DSP
Board.
Woori Align
Part
$8833
Aligner Sent Unknown Command From Host[03] (Head 3)
Occurs when Host(Component Placer) transfers unknown command to Aligner DSP
Board.
Try again after finding out again Home position by turning on the Aligner DSP Board by pressing and
releasing the <Emergency> switch of operation panel or teaching box.
Check for cable linked conditions between Aligner DSP Board and VME RS-232C I/F Board.
1-3-1
7-3-1
$8841
Aligner received zero length message[04] (Head 1)
Occurs when Aligner DSP Board receives incorrect data from Host(Component
Placer).
1-3-1
$8842
Aligner received zero length message[04] (Head 2)
Occurs when Aligner DSP Board receives incorrect data from Host(Component
Placer).
7-3-1
$8843
Aligner received zero length message[04] (Head 3)
Occurs when Aligner DSP Board receives incorrect data from Host(Component
Placer).
$8851
Aligner failed to write to Host[05] (Head 1)
Occurs when Aligner DSP Board can not respond to Host(Component Placer).
$8852
Aligner failed to write to Host[05] (Head 2)
Occurs when Aligner DSP Board can not respond to Host(Component Placer).
$8853
Aligner failed to write to Host[05] (Head 3)
Occurs when Aligner DSP Board can not respond to Host(Component Placer).
1-3-1
$8861
Aligner failed to read from Host[06] (Head 1)
Occurs when Aligner DSP Board can not receive data from Host(Component
Placer).
1-3-3
$8862
Aligner failed to read from Host[06] (Head 2)
Occurs when Aligner DSP Board can not receive data from Host(Component
Placer).
$8863
Aligner failed to read from Host[06] (Head 3)
Occurs when Aligner DSP Board can not receive data from Host(Component
Placer).
Try again after finding out again Home position by turning on the Aligner DSP Board by pressing and
releasing the <Emergency> switch of operation panel or teaching box.
Check for cable linked conditions between Aligner DSP Board and VME RS-232C I/F Board.
Try again after finding out again Home position by turning on the Aligner DSP Board by pressing and
releasing the <Emergency> switch of operation panel or teaching box.
Check for cable linked conditions between Aligner DSP Board and VME RS-232C I/F Board.
- 17 -
MODULE
ERROR
CODE
Symptom and Cause ACTION
Service
Manual
$8871
Aligner out of heap memory[07] (Head 1)
Error occurs to memory of Aligner DSP Board.
$8872
Aligner out of heap memory[07] (Head 2)
Error occurs to memory of Aligner DSP Board.
$8873
Aligner out of heap memory[07] (Head 3)
Error occurs to memory of Aligner DSP Board.
$8881
Aligner received invalid length of message[08] (Head 1)
Aligner DSP Board receives invalid data from Host(Component Placer).
$8882
Aligner received invalid length of message[08] (Head 2)
Aligner DSP Board receives invalid data from Host(Component Placer).
$8883
Aligner received invalid length of message[08] (Head 3)
Aligner DSP Board receives invalid data from Host(Component Placer).
$8891
Aligner Received Bad Reply Length[09] (Head 1)
Aligner DSP Board receives invalid data from Host(Component Placer).
$8892
Aligner Received Bad Reply Length[09] (Head 2)
Aligner DSP Board receives invalid data from Host(Component Placer).
$8893
Aligner Received Bad Reply Length[09] (Head 3)
Aligner DSP Board receives invalid data from Host(Component Placer).
$88A1
Aligner RAM Failed[10] (Head 1)
Error occurred to memory of Aligner DSP Board.
$88A2
Aligner RAM Failed[10] (Head 2)
Error occurred to memory of Aligner DSP Board.
$88A3
Aligner RAM Failed[10] (Head 3)
Error occurred to memory of Aligner DSP Board.
$88C1
Aligner Position Counter circuitry failed[12] (Head 1)
Error occurred to position counter circuit of Aligner DSP Board.
Woori Align
Part
$88C2
Aligner Position Counter circuitry failed[12] (Head 2)
Error occurred to position counter circuit of Aligner DSP Board.
$88C3
Aligner Position Counter circuitry failed[12] (Head 3)
Error occurred to position counter circuit of Aligner DSP Board.
$88D1
Aligner unable to reset the theta position counter[13] (Head 1)
Error occurred to position counter circuit of Aligner DSP Board.
$88D2
Aligner unable to reset the theta position counter[13] (Head 2)
Error occurred to position counter circuit of Aligner DSP Board.
1-3-1
Try again after finding out again Home position by turning on the Aligner DSP Board by pressing and
releasing the <Emergency> switch of operation panel or teaching box.
Check for cable linked conditions between Aligner DSP Board and VME RS-232C I/F Board.
