MODULE ERROR CODE Symptom and Cause ACTION Service Manual $C331 Z or R axis Homing failed searching sensor or zero phase (home03) (Head 1-z axis) Occurs when encoder zero phase fails to be On in the course of searching t…

MODULE

ERROR

CODE

Symptom and Cause ACTION

Service

Manual

$C231

Z or R axis Homing failed going out of home sensor (home02)

(Head 1-Z axis)

Occurs when home sensor fails to be Off in the course of escaping from Z-axis or

R-axis home sensor, or other troubles(motor driver error, etc.) are occurred during

escape.

In case caused by other errors, check the cause of other errors.

Check manually the ON/OFF switching conditions of Home sensor.

Check that home sensor of Z-axis or R-axis is detected properly by use of teaching box.

Motor & I/O

Part

$C232

Z or R axis Homing failed going out of home sensor (home02)

(Head 2-Z axis)

Occurs when home sensor fails to be Off in the course of escaping from Z-axis or

R-axis home sensor, or other troubles(motor driver error, etc.) are occurred during

escape.

$C233

Z or R axis Homing failed going out of home sensor (home02)

(Head 3-Z axis)

Occurs when home sensor fails to be Off in the course of escaping from Z-axis or

R-axis home sensor, or other troubles(motor driver error, etc.) are occurred during

escape.

$C241

Z or R axis Homing failed going out of home sensor (home02) (Head 1-R axis)

Occurs when home sensor fails to be Off in the course of escaping from Z-axis or

R-axis home sensor, or other troubles(motor driver error, etc.) are occurred during

escape.

$C242

Z or R axis Homing failed going out of home sensor (home02) (Head 2-R axis)

Occurs when home sensor fails to be Off in the course of escaping from Z-axis or

R-axis home sensor, or other troubles(motor driver error, etc.) are occurred during

escape.

$C243

Z or R axis Homing failed going out of home sensor (home02) (Head 3-R axis)

Occurs when home sensor fails to be Off in the course of escaping from Z-axis or

R-axis home sensor, or other troubles(motor driver error, etc.) are occurred during

escape.

$C310

X Axis Homing failed searching zero phase (home03)

Occurs when encoder zero phase fails to be On in the course of searching the X-

axis home sensor slowly, or other troubles(motor driver error, etc.) are occurred

during searching.

9-3-2

$C320

Y Axis Homing failed searching zero phase (home03)

Occurs when encoder zero phase fails to be On in the course of searching the Y-

axis home sensor slowly, or other troubles(motor driver error, etc.) are occurred

during searching.

In case caused by other errors, check the cause of other errors.

Check that Encoder line is linked properly..

In case caused by other errors, check the cause of other errors.

Check manually the ON/OFF switching conditions of Home sensor.

Check that home sensor of Z-axis or R-axis is detected properly by use of teaching box.

- 24 -

MODULE

ERROR

CODE

Symptom and Cause ACTION

Service

Manual

$C331

Z or R axis Homing failed searching sensor or zero phase (home03)

(Head 1-z axis)

Occurs when encoder zero phase fails to be On in the course of searching the Z-

axis or R-axis home sensor slowly, or other troubles(motor driver error, etc.) are

occurred during searching.

$C332

Z or R axis Homing failed searching sensor or zero phase (home03)

(Head 2-z axis)

Occurs when encoder zero phase or home sensor fails to be On in the course of

searching the Z-axis or R-axis home sensor slowly, or other troubles(motor driver

error, etc.) are occurred during searching.

5-3-2

$C333

Z or R axis Homing failed searching sensor or zero phase (home03)

(Head 3-z axis)

Occurs when encoder zero phase or home sensor fails to be On in the course of

searching the Z-axis or R-axis home sensor slowly, or other troubles(motor driver

error, etc.) are occurred during searching.

$C341

Z or R axis Homing failed searching sensor or zero phase (home03)

(Head 1-R axis)

Occurs when encoder zero phase or home sensor fails to be On in the course of

searching the Z-axis or R-axis home sensor slowly, or other troubles(motor driver

error, etc.) are occurred during searching.

5-3-2

$C342

Z or R axis Homing failed searching sensor or zero phase (home03)

(Head 2-R axis)

Occurs when encoder zero phase or home sensor fails to be On in the course of

searching the Z-axis or R-axis home sensor slowly, or other troubles(motor driver

error, etc.) are occurred during searching.

9-3-2

Motor & I/O

Part

$C343

Z or R axis Homing failed searching sensor or zero phase (home03)

(Head 3-R axis)

Occurs when encoder zero phase or home sensor fails to be On in the course of

searching the Z-axis or R-axis home sensor slowly, or other troubles(motor driver

error, etc.) are occurred during searching.

In case caused by other errors, check the cause of other errors.

For R-axis, check manually the ON/OFF switching conditions of Home sensor.

By use of teaching box, check that R-axis home sensor is detected properly.

$C521

Z-axis motor initialization failed (in103) (Head 1)

Occurs when Motor ID is incorrect or ID exceeds total No. of motors.

This error may occur together with other errors when connection condition of Z Axis

control board is improper.

$C522

Z-axis motor initialization failed (in103) (Head 2)

Occurs when Motor ID is incorrect or ID exceeds total No. of motors.

This error may occur together with other errors when connection condition of Z Axis

control board is improper.

In case caused by other errors, check the cause of other errors.

For Z-axis, check that enough spare space is supplied upwards in order to allow Z-axis to find the

Encoder Zero phase.

Check that Z-axis Encoder line is linked properly.

In case caused by other errors, check the cause of other errors.

For R-axis, check manually the ON/OFF switching conditions of Home sensor.

By use of teaching box, check that R-axis home sensor is detected properly.

- 25 -

MODULE

ERROR

CODE

Symptom and Cause ACTION

Service

Manual

$C523

Z-axis motor initialization failed (in103) (Head 3)

Occurs when Motor ID is incorrect or ID exceeds total No. of motors.

This error may occur together with other errors when connection condition of Z Axis

control board is improper.

3-3-1

$C531

Rotation motor initialization failed (in104) (Head 1)

Occurs when Motor ID is incorrect or ID exceeds total No. of motors.

This error may occur together with other errors when connection condition of R Axis

control board is improper.

3-3-2

$C532

Rotation motor initialization failed (in104) (Head 2)

Occurs when Motor ID is incorrect or ID exceeds total No. of motors.

This error may occur together with other errors when connection condition of R Axis

control board is improper.

5-3-2

$C533

Rotation motor initialization failed (in104) (Head 3)

Occurs when Motor ID is incorrect or ID exceeds total No. of motors.

This error may occur together with other errors when connection condition of R Axis

control board is improper.

$C621

Z-axis jogging failed (jog103) (Head 1)

Occurs when Jog Speed is transferred incorrectly,

when it fails to define Z axis with software,

caused by unsuitable Motor ID, or when ID exceeds total numbers of motor,

or when action(start or stop) for Motor Jog fails to be defined.

$C622

Z-axis jogging failed (jog103) (Head 2)

Occurs when Jog Speed is transferred incorrectly,

when it fails to define Z axis with software,

caused by unsuitable Motor ID, or when ID exceeds total numbers of motor,

or when action(start or stop) for Motor Jog fails to be defined.

$C623

Z-axis jogging failed (jog103) (Head 3)

Occurs when Jog Speed is transferred incorrectly,

when it fails to define Z axis with software,

caused by unsuitable Motor ID, or when ID exceeds total numbers of motor,

or when action(start or stop) for Motor Jog fails to be defined.

$C631

Rotation jogging failed (jog104) (Head 1)

Occurs when Jog Speed is transferred incorrectly,

when it fails to define R axis with software,

caused by unsuitable Motor ID, or when ID exceeds total numbers of motor,

or when action(start or stop) for Motor Jog fails to be defined.

Try again after Emergency stop.

If failed to recover with above corrective action, the error is caused by incorrect designation of Motor

ID or Speed in aspects of software error.

Check that POWER SUPPLY voltage(DC5V) is supplied properly.

- 26 -
