3. Setup
3 - 71
No. Abbr. Parameter name Details
Setting range
(Unit)
Standard
setting
SP017 TSP* Maximum motor speed
Set the maximum spindle motor speed. 1 to 32767
(r/min)
6000
SP018 ZSP* Motor zero speed
Set the motor speed for which zero-speed output is
performed.
1 to 1000
(r/min)
50
SP019 CSN1* Speed cushion 1
Set the time constant for a speed command from "0" to
the maximum speed.
(This parameter is invalid during position loop control.)
1 to 32767
(10 ms)
30
SP020 SDTS*
Speed detection set
value
Set the motor speed for which speed detection output is
performed.
Usually, the setting value is 10% of SP017 (TSP).
0 to 32767
(r/min)
600
SP021 TLM1 Torque limit 1 Set the torque limit rate for torque limit signal 001. 0 to 120 (%) 10
SP022
VGNP1*
Speed loop gain
proportional term under
speed control
Set the speed loop proportional gain in speed control
mode. When the gain is increased, response is
improved but vibration and sound become larger.
0 to 1000 63
SP023 VGNI1*
Speed loop gain integral
term under speed
control
Set the speed loop integral gain in speed control mode.
Normally, this is set so that the ratio in respect to SP022
(VGNP1) is approximately constant.
0 to 1000 60
SP024 Not used. Set "0". 0 0
SP025 GRA1*
Spindle gear teeth count
1
Set the number of gear teeth of the spindle
corresponding to gear 000.
1 to 32767 1
SP026 GRA2*
Spindle gear teeth count
2
Set the number of gear teeth of the spindle
corresponding to gear 001.
1 to 32767 1
SP027 GRA3*
Spindle gear teeth count
3
Set the number of gear teeth of the spindle
corresponding to gear 010.
1 to 32767 1
SP028 GRA4*
Spindle gear teeth count
4
Set the number of gear teeth of the spindle
corresponding to gear 011.
1 to 32767 1
SP029 GRB1*
Motor shaft gear teeth
count 1
Set the number of gear teeth of the motor shaft
corresponding to gear 000.
1 to 32767 1
SP030 GRB2*
Motor shaft gear teeth
count 2
Set the number of gear teeth of the motor shaft
corresponding to gear 001.
1 to 32767 1
SP031 GRB3*
Motor shaft gear teeth
count 3
Set the number of gear teeth of the motor shaft
corresponding to gear 010.
1 to 32767 1
SP032 GRB4*
Motor shaft gear teeth
count 4
Set the number of gear teeth of the motor shaft
corresponding to gear 011.
1 to 32767 1
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
3. Setup
3 - 72
No. Abbr. Parameter name Details
<For MDS-C1-SP/SPH>
FEDCBA98765 4 3 2 10
poff hzs ront
pycal
pychg
pyst pyoff sftk dflt
1a2m
bit Meaning when set to 0 Meaning when set to 1 Standard
0 1a2m 1 drive unit 2 motor function: Invalid 1 drive unit 2 motor function: Valid 0
1 dflt Default motor: Main Default motor: Sub 0
2 sftk Without SF-TK card With SF-TK card 0
3 0
4 0
5 0
6pyoff 0
7pyst 0
8pychg
This is used by Mitsubishi. Set to "0" unless particularly designated.
0
9 pycal (Conventional specifications)
High-speed rate deceleration
method valid for minimum excitation
rate
0
A 0
B 0
C ront Normal ready ON High-speed ready ON 0
D 0
Ehzs
Gate OFF by high-cycle zero speed
invalid
Gate OFF by high-cycle zero speed
valid
0
F poff
Contactor hold at NC power OFF
invalid
Contactor hold at NC power OFF
valid
0
(Note 1) bits 0, 1 and 2 are invalid for SPH.
(Note 2) Set 0 if there is no particular explanation for the bit.
SP033 SFNC1* Spindle function 1
<For MDS-C1-SPX/SPHX>
FEDCBA98765 4 3 2 10
poff hzs
sfnc1
ront
pycal
pychg
pyst pyoff
bit Meaning when set to 0 Meaning when set to 1 Standard
0 0
1 0
2 0
3 0
4 0
5 0
6pyoff 0
7pyst 0
8pychg
This is used by Mitsubishi. Set to "0" unless particularly designated.
0
9 pycal (Conventional specifications)
High-speed rate deceleration
method valid for minimum excitation
rate
0
A 0
B 0
C ront Normal ready ON High-speed ready ON 0
D sfnc1 MDS-B-PJEX connection invalid MDS-B-PJEX connection valid 1
Ehzs
Gate OFF by high-cycle zero speed
invalid
Gate OFF by high-cycle zero speed
valid
0
F poff
Contactor hold at NC power OFF
invalid
Contactor hold at NC power OFF
valid
0
(Note) Set 0 if there is no particular explanation for the bit.
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
3. Setup
3 - 73
No. Abbr. Parameter name Details
<For MDS-C1-SPM>
FEDCBA98765 4 3 2 10
poff
ront
bit Meaning when set to 0 Meaning when set to 1 Standard
0 0
1 0
2 0
3 0
SP033 SFNC1* Spindle function 1
4 0
5 0
6 0
7 0
8 0
9 0
A 0
B 0
C ront Normal ready ON High-speed ready ON 0
D 0
E 0
F poff
Contactor hold at NC power OFF
invalid
Contactor hold at NC power OFF
valid
0
(Note) Set 0 if there is no particular explanation for the bit.
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
