2. Wiring and Connection
2 - 5
2-2-2 Connector pin assignment
CAUTION
Do not apply a voltage other than that specified in Instruction Manual on each
terminal. Failure to observe this item could lead to rupture or damage, etc.
(1) Main circuit terminal block
Power supply unit
Unit
Terminal
MDS-C1-CV-37 to 75 MDS-C1-CV-110 to 370
Terminal
position
[1] TE1
Compatible unit CV-37 to 75
Screw size
M4
Tightening torque
1.6Nm
Compatible unit CV-110 to 185 CV-220 to 370
Screw size
M5 M8
Tightening torque
3.37Nm 13.2Nm
[2] TE2
Compatible unit CV-37 to 370
Screw size
M6
Tightening torque
5.0Nm
[3] TE3
Compatible unit CV-37 to 75 CV-110 to 370
Screw size M4 M4
Tightening torque 2.0Nm 1.6m
Terminal specification/Pin assignment
[4]
Compatible unit CV-37 to 75
Screw size M4
Tightening torque 2.0Nm
Compatible unit CV-110 to 185 CV-220 to 370
Screw size M5 M8
Tightening torque 3.37Nm 13.2Nm
[2]
[3]
[1]
[4]
[2]
[3]
[4]
[1]
U V W
L+
L-
L11
L21
MC1
U V W
2. Wiring and Connection
2 - 6
Servo/spindle drive unit
Unit
Terminal
MDS-C1-V1-10 and
smaller
MDS-C1-SP-15 and
smaller
MDS-C1-V1-20 and
larger
MDS-C1-SP-22 and
larger
MDS-C1-V2-1010 and
smaller
MDS-C1-V2-2010 and
larger
Terminal
position
[1] TE1
V1- 01 to 35 45S,45 to 90 110 to 150
V2- 0101 to 9090S -
Compatible unit
SP- 04 to 37 55 to 185 220 to 300
Screw size M4 M5 M8
Tightening torque 2.0Nm 3.2Nm 13.2Nm
[2] TE2
Compatible unit All V1/V2/SP
Screw size M6
Tightening torque 5.0Nm
[3] TE3
Compatible unit All V1/V2/SP
Screw size M4
Tightening torque 2.0Nm
Terminal specification/Pin assignment
[4]
The PE screw size is the same as TE1.
[
2
]
[
3
]
[
1
]
[
4
]
[
2
]
[
3
]
[1]
[4]
[
2
]
[
3
]
[
1
]
[
4
]
[
2
]
[
3
]
[
1
]
[
4
]
MU MV MW
LU LV LW
MU MV MW
LU LV LW
U V W
U V W
L+
L-
L11
L21
2. Wiring and Connection
2 - 7
(2) Control circuit connector
Unit
Terminal
MDS-C1-V1 MDS-C1-V2
Connector
position
[1] CN1A
[2] CN1B
[3] CN9
[4] CN4
[5] CN2L
[6] CN3L
[7] CN2M
[8] CN2M
Connector s
p
ecifications
[9] CN20
(Note) The [5] and [6] connector names diff er for the MDS-C1-V1 unit. (CN2L, CN3L → CN2, CN3)
[
1
]
[
3
]
[
5
]
[
2
]
[
4
]
[
9
]
[
6
]
[
1
]
[
3
]
[
5
]
[
2
]
[
4
]
[
9
]
[
6
]
[
8
]
[
7
]
Pin No.
No.1
No.10
No.11
No.20
No.1
No.2
No.3
Pin No.
