Appendix 1. Cable and Connector Specifications
A1 - 6
Appendix 1-2 Cable connection diagram
CAUTION
1. Do not mistake the connection when manufacturing the detector cable.
Failure to observe this could lead to faults, runaway or fires.
2. Do not connect anything to pins unless otherwise particularly specified when
manufacturing a cable. (Leave OPEN)
3. Contact Mitsubishi when manufacturing a cable longer than 30m.
(1) NC bus cable
<SH21 cable connection diagram>
Drive unit side connector
Connector: 10120-3000VE
Shell kit: 10320-52F0-008
Drive unit side connector
Connector: 10120-3000VE
Shell kit: 10320-52F0-008
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
PE
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
PE
FG
Appendix 1. Cable and Connector Specifications
A1 - 7
(2) Servo detector cable
<CNV12/CNV13 cable connection diagram> The connection differs according to the cable length.
Servo drive unit side connecto
r
Connector: 10120-3000VE
(One-touch type lock)
Shell kit: 10320-52F0-008
(Screw-type lock)
Shell kit: 10320-52A0-008
H
J
K
L
E
S
R
N
6
16
7
17
9
19
10
20
1
11
PE
SD
SD*
RQ
RQ*
BAT
P5(+5V)
LG
FG
<For 20m or less>
Servomotor detector side/
Ball screw end detector side connector
<For general environment>
Plug: MS3106B22-14S (Straight)
MS3108B22-14S (Angle)
Clamp: MS3057-12A
<IP65 compatible>
Plug:
MS3106A22-14S(D190)
Straight back shell:
CE02-22BS-S (Straight)
CE-22BA-S (Angle)
Clamp: CE3057-12A-3
H
J
K
L
E
S
R
N
6
16
7
17
9
19
10
20
1
11
PE
SD
SD*
RQ
RQ*
BAT
P5(+5V)
LG
FG
<For 20m to 30m>
Appendix 1. Cable and Connector Specifications
A1 - 8
<CNL3H1,CNL3H2,CNL3H1-S,CNL3H2-S cable connection diagram>
Servo drive unit sid e conne cto r
Connector:10120-3000VE
(One-touch type lock)
Shell kit:10320-52F0-008
(Screw-type lock)
Shell kit: 10320-52A0-008
MDS-B-HR unit side connector
Plug: RM15WTP-8S
Clamp: RM15WTP-CP(10)
6
16
7
17
19
10
20
1
11
PE
3
4
1
2
5
6
7
8
PE
SD
SD*
RQ
RQ*
P5(+5V)
P5(+5V)
LG
LG
FG
