2. Wiring and Connection 2 - 20 (3) Connecting the linear scale (for serial data output) MDS-C1-V1 CN2 CN3 Name LG SD* RQ* P5(+5V) P5 ( +5V ) Pin 11 12 13 14 15 16 17 18 19 20 Name LG SD RQ BA T P5 ( +5V ) Pin 1 2 3 4 5 …
2. Wiring and Connection
2 - 19
(2) Connecting the linear scale (for oblong wave data output)
MDS-C1-V1
CN2 CN3
Name
LG
A*
B*
Z*
P5(+5V)
P5
(
+5V
)
Pin
11
12
13
14
15
16
17
18
19
20
Name
LG
A
B
Z
BAT
P5
(
+5V
)
Pin
1
2
3
4
5
6
7
8
9
10
CNV12
Servomotor
Table
U V W
Pin No.
Detector connector : CN3
No.1
No.10
No.11
No.20
Max. 30m
Linear scale
2. Wiring and Connection
2 - 20
(3) Connecting the linear scale (for serial data output)
MDS-C1-V1
CN2 CN3
Name
LG
SD*
RQ*
P5(+5V)
P5
(
+5V
)
Pin
11
12
13
14
15
16
17
18
19
20
Name
LG
SD
RQ
BAT
P5
(
+5V
)
Pin
1
2
3
4
5
6
7
8
9
10
CNV12
Servomotor
Table
U V W
Pin No.
Detector connector : CN3
No.1
No.10
No.11
No.20
Max. 30m
Linear scale
2. Wiring and Connection
2 - 21
(4) Connecting the linear scale (for analog output)
MDS-C1-V1
CN2 CN3
Detector
converter unit
MDS-B-HR
CON1 CON2
CON3
CON4
CNL3-H2
CNLH3
Name
LG
SD*
RQ*
P5(+5V)
P5
(
+5V
)
Pin
11
12
13
14
15
16
17
18
19
20
Name
LG
SD
RQ
BAT
P5
(
+5V
)
Pin
1
2
3
4
5
6
7
8
9
10
CNV12
Servomotor
Table
U V W
Pin No.
Detector connector : CN3
No.1
No.10
No.11
No.20
Max. 30m
Linear scale
