Samsung Component Placer CP-45F(V)/FS Reference Manual
viii
About Warranty
The warranty is issued to cover the following machine faults and malfunctions:
What is covered
by the warranty
If any part of the equipment fails to function properly under
normal usage due to defects in material or workmanship, it will
be repaired by Samsung Techwin Co., Ltd. at no charge for
either parts or labor.
Time period of
the warranty
The term of this warranty shall expire for any of the following
cases.
y 18 months have elapsed after the delivery of the product
y 1 year has elapsed after installation of the product
y 2,400 hours have elapsed after the commencement of
operation.
What is not
covered by the
warranty
Any of the following cases are not covered by this warranty
y Data lost due to HDD damage. Back up is desirable.
y Malfunction of the machine due to running applications,
which are not any part of the machine, or infected by any
computer viruses.
y Normal wear and tear due to long-term use or faults arising
from normal use (natural fading of coating and plating,
wearing-out of parts, etc.)
y Delicate changes do not affect the functional quality of the
product (such as noise of an operating controller, sound of
a rotating motor, etc.)
y Faults due to the ambient conditions (moisture, impurities,
dust on the machine, oil mist, etc.)
Faults resulting from the following cases are not covered by
this warranty as well:
y Natural disasters such as earthquake, typhoon, flood,
lightning strike, etc., or accident, and fire.
y Reconstruction which is not approved by our company or
agents.
y Not performing back up for the data stored in the
equipment.
y Use of parts or lubricating oil which are not designated
y Insufficient or faulty maintenance or inspection.
y Adjustments performed by persons other than designated
agents.
However, the contents of the warranty stipulated at the time of purchase take precedence
over the above coverage.
Preface
ixix
About This Manual
Related manuals
Manuals related to this manual are listed below:
Operations manual of this machine.
à Overview, Programming Guide
Reference Manual of this machine.
à Maintenance Guide, Troubleshooting Guide
Typographical conventions
A number of typographical features and conventions used in this manual.
Text indicated in italics in quotation marks (" ") denotes the title of a manual, or
the title of a chapter or section included in reference. If the title of a section is to
be referred to, the corresponding page number is also shown.
Please refer to "Chapter 1. Menu Structure of MMI" of "Operations Manual".
Please refer to "1.1 MMI of this Machine (page 1-1)".
Characters in quotation marks (" ") denote the title of a dialog box or message
box encountered while operating MMI.
An "open" dialog box is taken as an example.
Characters in angle brackets (< >) denote a button within a dialog box or
message box, or a button or icon to be clicked in the title, keyboard, or teaching
box. When explaining about a dialog box or message box, titles within a box are
shown along with a distinct sign (, y, à, etc.).
Click <OK> button.
The following texts are entered in the <Code Description>.
Description Code
<OK> button
Characters in brackets([ ]) denote keys to be pressed simultaneously on the
keyboard or in the teaching box. Each key is coupled by a plus (+) sign.
New command [Ctrl + N]
Samsung Component Placer CP-45F(V)/FS Reference Manual
x
Symbols used in this manual
The meaning of symbols used in this manual are as follows:
Reference indicates a part to be referred to.
Memo shows useful information related to the text or definition of terms.
The operations procedures for MMI, installation of a teaching box or machine are
described. Each step of procedure is indicated by a number.
"Memo
)Reference
2Operational procedure
