7 Troubleshooting
7.1 Overview
If you have difficulty operating your cure module, use this section to identify a possible solution to the
problem. If you have difficulties not listed in this section, or the suggested solution does not correct the
problem, contact Nordson ASYMTEK Technical Support.
7.2 Safety First
Operation of your UV-9 Cure Module involves air pressure, electrical power, mechanical devices, and
potentially the use of hazardous materials. It is essential that every person servicing or operating the cure
module fully understands all hazards, risks, and safety precautions. Refer to Section 2 – Safety for
important safety information.
WARNING! CAUTION!
Allow only qualified personnel to perform system troubleshooting. Observe and
follow the safety instructions in this document and all other related documentation.
Failure to do so may cause serious bodily injury to the user or damage to the
equipment.
7.3 Record Keeping
The type of procedure performed should be recorded in maintenance records for the dispensing system.
Dates, part numbers/serial numbers of replaced parts, names of technicians, and other pertinent data
should be recorded.
7.4 Alarms
Table 7-1 lists system alarms, possible causes and suggested recovery procedures.
Table 7-1 Alarms
Alarms
Possible Cause
Recovery
Top Lamp Ballast Fault 1
Wrong connection
Defective ballast
Check connection.
Replace ballast.
Top Lamp Ballast Fault 2
Mains failure
Fuse blown
Short circuit in lamp circuit
Defective ballast
Check if KM1 is ON.
Check the fuses F2.
Check wiring integrity.
Replace ballast.
Top Lamp Ballast Fault 3
UV lamp shut off
UV lamp does not ignite
Disconnection to the lamp
Contact Nordson ASYMTEK.
Top Lamp Ballast Fault 4-1 Ballast overheating See ballast technical sheet.
Top Lamp Ballast Fault 4-2 Ground fault in lamp circuit Check the circuit integrity.
Troubleshooting 7-1
Alarms
Possible Cause
Recovery
Top Lamp Ballast Fault 4-3 Missing phase on mains
Check fuses F2.
Check the facility mains.
Top Lamp Thermostat Fault No UV lamp cooling
Check if the exhaust pump turns.
Check the thermostat of the UV
lamp.
Check if the power plug is well
connected.
Check if the exhaust is not
blocked.
Top Lamp Pressure
Exhaust Fault
Exhaust pump not working
Exhaust blocked
Check circuit breaker Q12.
Check relay KM3.
Check the exhaust.
PLC Data Error
System error of the PLC
which indicates that data was
lost
Verify the oven’s parameters. Check
option’s parameters and rewrite
them if necessary.
PLC IO Error
PLC module default
PLC module out of order
Check for red LED on different
module and erase the default on the
computer. If there is no effect,
replace the module.
Bottom Lamp Ballast Fault 1
Wrong connection
Defective ballast
Check connection.
Replace ballast.
Bottom Lamp Ballast Fault 2
Mains failure
Fuse blown
Short circuit in lamp circuit
Defective ballast
Check if KM2 is ON.
Check the fuses F3.
Check wiring integrity.
Replace ballast.
Bottom Lamp Ballast Fault 3
UV lamp shut off
UV lamp does not ignite
Disconnection to the lamp
Contact Nordson ASYMTEK.
Bottom Lamp Ballast Fault 4-1 Ballast overheating See ballast technical sheet.
Bottom Lamp Ballast Fault 4-2 Ground fault in lamp circuit Check the circuit integrity.
Bottom Lamp Ballast Fault 4-3 Missing phase on mains
Check fuses F3.
Check the facility mains.
Bottom lamp thermostat fault No UV lamp cooling
Make sure the exhaust pump
turns.
Check the thermostat of the UV
lamp.
Make sure the power plug is
connected.
Make sure the exhaust is not
blocked.
Bottom lamp pressure exhaust
fault
Exhaust pump not working
Exhaust blocked
Check circuit breaker Q12.
Check relay KM4.
Check the exhaust.
Inlet Jam PCB Track A PCB stuck
Warning! Before reaching into the
workspace to clear the board jam,
Outlet Jam PVB Track A PCB stuck
7-2 Troubleshooting
