2.13.2 Low Voltage Indicator Light
An indicator LED on the operator’s control panel warns the operator of conditions preventing UV-9 Cure
Module operation.
2.13.3 Light Beacon
The light beacon mounted on the top of the UV-9 Cure Module is a device that displays system status.
The beacon has three different colored lights, that can be constantly ON or flashing, and a buzzer. See
Table 2-3 for an explanation of each color indication. See 5.7.3 Alarms for recovery instructions.
Table 2-3 Beacon Color Indications
Beacon Color System Status
GREEN
Blinking: The UV-9 Cure Module is ready but the conveyor is empty.
Steady: The cure module is ready and a board is on the conveyor.
ORANGE
Blinking: The UV-9 Cure Module is waiting for production and the UV
lamp is in standby.
Steady: The cure module is in the stabilization step (start up).
RED
Blinking: Alarm not acknowledged.
Steady: The UV-9 Cure Module is in an alarm condition. See the active
alarm(s) on the Alarm screen.
BUZZER The buzzer sounds when a default appears
2.14 Transportation and Storage
Long term storage of the UV-9 Cure Module should be on the handling pallet protected from humidity,
bad weather, and temperature extremes.
Safety 2-15
3 Installation
3.1 Overview
This section covers the following topics:
• Facility Requirements
• Connecting SMEMA Cables
• Tools and Materials Needed
• Connecting the PLC to Upstream Equipment
• Unpacking and Placing the UV-9 Cure
Module
• Connecting the Exhaust
• Unpacking the Accessories
• Anchoring
• Leveling the UV-9 Cure Module
• Initial Startup
• Connecting the Power
• Shut Down
3.2 Safety First
Before performing any of the UV-9 Cure Module installation procedures in this section, please review the
information provided in Section 2 – Safety.
WARNING! Allow only qualified personnel to perform the following tasks. Follow the safety
instructions in this document and all other related documentation.
3.3 Facility Requirements
To ensure optimal performance and safety, it is necessary to install the UV-9 Cure Module in a facility
that meets or exceeds the requirements listed in 8.3 Facility Requirements.
If you have any questions about facility requirements, please contact Nordson ASYMTEK Technical
Support.
WARNING! CAUTION!
Make sure that your facility meets all requirements listed in 8.3 Facility
Requirements. Failure to meet these requirements could result in serious bodily
injury to personnel and damage to the UV-9 Cure Module.
3.4 Tools and Materials Needed
• Adjustable Wrench
• Forklift
• Hammer
• Appropriate Personal Protective Equipment
• Flat Bar
Installation 3-1
