Alarms Possible Cause Recovery
Inlet Jam PCB Track B
PCB stuck
either switch the UV-9 Cure Module
off, or wear 300 gram cotton gloves
and long sleeves or arm covering
clothing as well as face and eye
protection (e.g. protective welding
goggles).
Check the alignment of the
conveyors.
Check the width of the oven
conveyor.
Outlet Jam PVB Track B PCB stuck
Rotation alArm Track A
Mechanical sticking
Electrical failure
Check if a PCB is not stuck on
the conveyor.
Check chain tension.
Check circuit breaker Q8.
Rotation Alarm Track B
Mechanical sticking
Electrical failure
Check if a PCB is not stuck on
the conveyor.
Check chain tension.
Check circuit breaker Q9.
Hood opened Warning message Close the hood.
Emergency stop Warning message
Reset the emergency stop after
fixing the defect.
Downstream not ready
Track A
Warning message
Check if the downstream conveyor is
ON or if a PCB is stuck on it.
Downstream not ready
Track B
Warning message
Check if the downstream conveyor is
ON or if a PCB is stuck on it.
Troubleshooting 7-3
8 Technical Data
8.1 Overview
This chapter provides technical data for the UV-9 Cure Module. This data is intended as a convenient
reference for personnel planning system relocation, installation, or operation and others who may have an
interest in system performance characteristics. This chapter provides the following:
• Facility Requirements
• Declaration of Conformity
• System Specifications
• Seismic Safety
• Recommended Working Area Allowances
8.2 Safety First
Familiarity with the performance specifications and facility requirements in this section can provide
information leading to safe operation of the curing system. For additional safety information, see
Section 2 – Safety.
8.3 Facility Requirements
Table 8-1 lists the specifications and requirements for the system and applicable options which must be
supplied by the customer. Power cords are supplied by Nordson MARCH.
Table 8-1 Facility Requirements
Item
Requirement
Power 400VAC 3 phase
Power Rating
Top Lamp
Top and Bottom Lamps
7 kW
14 kW
Mode N+EARTH, TT or TN
Main Power Supply 100/120/220/240 VAC, 50/60 Hz, 10 A
Ventilation Air Exhaust
550 m
3
/h (top lamp)
1100 m
3
/h (top and bottom lamps)
(382.5 SCFM @ 1.57 in. WC, 10 in. exhaust duct)
See 3.11 Connecting the Exhaust for more information.
Pneumatic Connection (optional)
(For systems equipped with entrance
and/or exit shutters)
Air Pressure: 600 kPa (87 psi)
Connecting Pipe: 6 mm
Consumption: < 0.02 m
3
/H
See 3.12 Pneumatic Connection (Shutter Option).
WARNING! CAUTION!
The UV-9 Cure Module is not compatible with Neutral IT.
Technical Data 8-1
