8.6 System Specifications
8.7 Seismic Safety
The UV-9 System is structurally designed to withstand seismic activity in accordance with industry
standards.
Figure 8-1 through Figure 8-3 show the weight distribution and center of mass for a typical UV-9 System.
Figure 8-1 Weight Distribution
62.5 kg
(138 lbs.)
62.5 kg
(138 lbs.)
62.5 kg
(138 lbs.)
62.5 kg
(138 lbs.)
Technical Data 8-5
Figure 8-2 Center of Gravity – Front
Figure 8-3 Center of Gravity - Side
8.8 Recommended Working Area Allowances
Figure 8-4 and Figure 8-5 provide an overall view of the minimum service space allowance for the UV-9
Cure Module.
Figure 8-4 Recommended Working Allowances - Front View
8-6 Technical Data
Figure 8-5 Recommended Working Allowances - Top View
Technical Data 8-7
