Peripheral Devices 139
● Flat Cable
21.3
(23)
8.3
20
9.2
9.5
Conversion Connector for Standard Thin Cable and
Flat Cable
DCN4-BR4D
33.60
13.50
16.20
4.55
6
3
17
29
20.90
Power Supply Terminal Block with Terminating Resistance
for Flat Cable
DCN4-TP4D
22
17
17.8
30.7
9.5
13.8
Flat Connector Socket
DCN4-TR4
21.3
(23)
8.3
20
9.2
9.5
Flat Connector Plug
DCN4-BR4
140 Peripheral Devices
■ I/O Connectors for Connector Terminals
●MIL Connectors
Applicable Connectors
* DeviceNet connectors for multi-drop wiring cannot be used with the Hood Cover.
Cable Models
Applicable Cables with Connectors
● Cables with Connectors (1-to-2 Connection)/XW2Z-R@@-@-D@
● Cables with Connectors (1-to-1 Connection)/XW2Z-C@@K
● Cables with Crimp Terminals (at the End of Loose Wires)/XW2Z-RY@C-D1
I/O Peripheral Devices
Type Model Remarks
Flat Cable Pressure-welded Connectors XG4M-4030-T
Pressure-welded
Connectors with
Loose Wires
Socket
XG5M-4032-N Corresponding to 24 AWG
XG5M-4035-N Corresponding to 28 to 26 AWG
Semicover XG5S-2001
Hood Cover * XG5S-4022
Type Model Connected device Applicable models
Cable with Connectors (1:2)
XW2Z-RI@@-@@-D1
G7TC/G70D/G70A
DRT2-ID32ML
XW2Z-RM@@-@@-D1 DRT2-MD32ML
XW2Z-RO@@-@@-D1 DRT2-OD32ML/DRT1-OD32ML-1
XW2Z-RI@@-@@-D2 DRT2-ID32ML-1
XW2Z-RM@@-@@-D2 DRT2-MD32ML-1
Cable with Connector (1:1) XW2Z-C@@K
--
All modelsCable with Loose Wires with Crimp Terminals XW2Z-RY@00C-D1
Cable with Loose Wires XW2Z-RA@00C-D1
Appearance
Cable length (mm)
Model
500 250
XW2Z-RI50-25-D1
750 500
XW2Z-RI75-50-D1
500 250
XW2Z-RO50-25-D1
750 500
XW2Z-RO75-50-D1
500 250
XW2Z-RM50-25-D1
750 500
XW2Z-RM75-50-D1
500 250
XW2Z-RI50-25-D2
750 500
XW2Z-RI75-50-D2
500 250
XW2Z-RM50-25-D2
750 500
XW2Z-RM75-50-D2
Appearance Cable length (mm) Model
250
XW2Z-C25K
500
XW2Z-C50K
Appearance Cable length (mm) Model
1,000
XW2Z-RY100C-D1
2,000
XW2Z-RY200C-D1
5,000
XW2Z-RY500C-D1
A
B
Length without any bending
A
B
(120)
L
L
Connected
to device
300
Terminal A Terminal B
Peripheral Devices 141
● Cables with Loose Wires/XW2Z-RA@C
Appearance Cable length (mm) Model
2,000
XW2Z-RA200C-D1
5,000
XW2Z-RA500C-D1
L
300
Connected
to device
Terminal A Terminal B
