Digital I/O Units GT1- @ D16(-1)/ @ D16MX(-1)/ @ D16ML(-1)/ @ D32ML(-1)/ @ D16 77 Dimensions (Unit: mm) 27.6 37.4 65 max. 35 4 12.6 ( 88 .3) 140 max. 8 0 max. ● T erminal Block Model GT1-ID16 GT1-ID16-1 GT1-OD16 GT1-OD16…
76
Digital I/O Units
GT1-
@
D16(-1)/
@
D16MX(-1)/
@
D16ML(-1)/
@
D32ML(-1)/
@
D16
Cables for I/O Connector
Cables for Connector Terminal Conversion Units (16 Points)
Cables for Connector Terminal Conversion Units (32 Points)
Cables for I/O Blocks (16 Points)
Cables for I/O Blocks (32 Points)
Note 1: For details of applicable cables and connectors, refer to Peripheral Devices.
*1. Product no longer available to order.
I/O classification Model Applicable cable Connectable model
Connector Products
(Connector-Terminal Block Conversion Units)
Connecting method
Digital input (16 points)
GT1-ID16ML(-1)
XW2Z-@@@A
XW2R-J20G-T Phillips screw M3
XW2R-E20G-T Slotted screw M3
XW2R-P20G-T Push-in spring
XW2E-20G5-IN16
Phillips screw Common terminal
(3-tier input type) M3.5
Digital output (16 points)
GT1-OD16ML(-1)
XW2R-J20G-T Phillips screw M3
XW2R-E20G-T Slotted screw M3
XW2R-P20G-T Push-in spring
I/O classification Model Applicable cable Connectable model
Connector Products
(Connector-Terminal Block Conversion Units)
Connecting method
Digital input (32 points)
GT1-ID32ML(-1)
XW2Z-@@@B
XW2R-J40G-T Phillips screw M3
Digital output (32 points)
GT1-OD32ML(-1)
XW2R-E40G-T Slotted screw M3
XW2R-P40G-T Push-in spring
I/O classification Model Applicable cable Connectable model Remarks
Digital input (16 points)
NPN
GT1-ID16ML
XW2Z-R@C
G7TC-ID16
G7TC-IA16
For I/O Block input
Digital input (16 points)
PNP
GT1-ID16ML-1
G7TC-ID16-1
G7TC-IA16-1
For I/O Block output
Digital output (16 points)
NPN
GT1-OD16ML
G7TC-OC16
G7TC-OC08
G70D-SOC16
G70D-FOM16
G70D-VSOC16
G70D-VFOM16
G70A-ZOC16-3
For I/O Block output
M7E Series *1 Digital Display Unit
Digital output (16 points)
PNP
GT1-OD16ML-1
G7TC-OC16-1
G70D-SOC16-1
G70A-ZOC16-4
For I/O Block output
M7E-01MB@-@@ *1 Digital Display Unit
I/O classification Model Applicable cable Connectable model Remarks
Digital input (32 points)
NPN
GT1-ID32ML
XW2Z-RI@C-@
G7TC-ID16
G7TC-IA16
For I/O Block input
Digital input (32 points)
PNP
GT1-ID32ML-1
G7TC-ID16-1
G7TC-IA16-1
For I/O Block input
Digital output (32 points)
NPN
GT1-OD32ML
XW2Z-RO@C-@
G7TC-OC16
G7TC-OC08
G70D-SOC16
G70D-FOM16
G70D-VSOC16
G70D-VFOM16
G70A-ZOC16-3
For I/O Block output
Digital output (32 points)
PNP
GT1-OD32ML-1
G7TC-OC16-1
G70D-SOC16-1
G70D-FOM16-1 *1
G70A-ZOC16-4
For I/O Block output
Digital I/O Units
GT1-
@
D16(-1)/
@
D16MX(-1)/
@
D16ML(-1)/
@
D32ML(-1)/
@
D16
77
Dimensions (Unit: mm)
27.6
37.4
65 max.
35
4
12.6
(88.3)
140 max.
80 max.
● Terminal Block Model
GT1-ID16
GT1-ID16-1
GT1-OD16
GT1-OD16-1
Note: Accessory cable included.
27.6
37.4
4
65 max.
12.6
(69.3)
35
60 max.110 max.
● Connector Model
GT1-ID16MX
GT1-ID16MX-1
GT1-OD16MX
GT1-OD16MX-1
Note: Accessory cable included.
60
65
4
35
12.6
50
(59)
(78)
6
7.6
65
27.6
37.4
● Connector Model
GT1-ID16ML
GT1-ID16ML-1
GT1-OD16ML
GT1-OD16ML-1
Note: Accessory cable included.
60
65
4
35
12.6
50
(59)
(84)
6
7.6
65
27.6
37.4
● Connector Model
GT1-ID16DS
GT1-ID16DS-1
GT1-OD16DS
GT1-OD16DS-1
Note: Accessory cable included.
27.6
37.4
110 max.
4
65 max.
12.6
60 max.
(69.3)
35
● High-density Connector Model
GT1-ID32ML
GT1-ID32ML-1
GT1-OD32ML
GT1-OD32ML-1
Note: Accessory cable included.
78
Digital I/O Units
GT1-
@
D16(-1)/
@
D16MX(-1)/
@
D16ML(-1)/
@
D32ML(-1)/
@
D16
Wiring Diagrams
GT1-ID16 GT1-ID16-1
GT1-OD16 GT1-OD16-1
GT1-ID16MX GT1-ID16MX-1
GT1-OD16MX GT1-OD16MX-1
0123456789101112131415
VVVVVVVVVVVVVVVVV
GGGGGGGGGGGGGGGGG
I/O power supply
Three-wire sensor
with NPN output
(e.g., photoelectric
sensor or proximity sensor)
Three-wire sensor
with NPN output
(e.g., photoelectric
sensor or proximity sensor)
Two-wire sensor
(Limit switch, etc.)
24VDC
Brown
(red)
Blue
(black)
Black
(white)
Black
(white)
Blue
(black)
Brown
(red)
Brown
(white)
Blue
(black)
0123456789101112131415
VVVVVVVVVVVVVVVVV
GGGGGGGGGGGGGGGGG
Three-wire sensor with
PNP output
(e.g., photoelectric sensor
or proximity sensor)
Three-wire sensor with
PNP output
(e.g., photoelectric sensor
or proximity sensor)
Two-wire sensor
(Limit switch, etc.)
24VDC
I/O power supply
Brown
(red)
Blue
(black)
Black
(white)
Black
(white)
Blue
(black)
Brown
(red)
Brown
(white)
Blue
(black)
012345678 9 101112131415
VVVVVVVVVVVVVVVVV
GGGGGGGGGGGGGGGG
G
24VDC
I/O power supply
Solenoid valve, etc. Solenoid valve, etc.
012345678 9 101112131415
VVVVVVVVVVVVVVVVV
GGGGGGGGGGGGGGGG
G
24VDC
I/O power supply
Solenoid valve, etc. Solenoid valve, etc.
Three-wire sensor with
NPN output
(e.g., photoelectric sensor
or proximity sensor)
Two-wire sensor
(Limit switch, etc.)
8Contact 9 10 11 12 13 14 15
0Contact 1 2 3 4 5 6 7
GV
Signal
I/O power supply
24 VDC
VG
Black
(white)
Blue
(black)
Brown
(red)
Brown
(white)
Blue
(black)
Three-wire sensor with
PNP output
(e.g., photoelectric sensor
or proximity sensor)
Two-wire sensor
(Limit switch, etc.)
8Contact 9 10 11 12 13 14 15
0Contact 1 2 3 4 5 6 7
GV
I/O power supply
24 VDC
VG
Signal
Black
(white)
Blue
(black)
Brown
(red)
Brown
(white)
Blue
(black)
Solenoid valve, etc.
8Contact 9 10 11 12 13 14 15
0Contact 1 2 3 4 5 6 7
GV
I/O power supply
24 VDC
VG
Signal
Solenoid valve, etc.
8Contact 9 10 11 12 13 14 15
0Contact 1 2 3 4 5 6 7
GV
I/O power supply
24 VDC
VG
Signal
