152 Peripheral Devices ● Envir onment-resis tive Models for Thic k Wires with 7/8-16UN Mini Connectors 1 2 3 4 5 62.5 L 61.2 26 dia. 26 dia. 12 dia. 15 2 3 4 Thic k Cable with Connectors on Both Ends (5 Cond uctors for C…

100%1 / 199
Peripheral Devices 151
4.5 dia.
4.5
73
4.5 dia.
30.5
27
99
82
12
34
5
M12
2
3
5
1
4
500
+60
−0
2754
33
9
20
13.5
9
15
PORT 1 PORT 2 PORT 3 PORT 4
1
5
Shielded Branch Relay Box with Four Ports
DCN2-S4C5H1
Wiring
Terminal No. Color Name
1 - DRAIN
2RedV+
3BlackV-
4 White CAN H
5BlueCAN L
Connections Diagram
Shielded Branch Relay Box with Eight Ports
DCN2-S8C5H1
Wiring
Terminal No. Color Name
1 - DRAIN
2RedV+
3BlackV-
4 White CAN H
5BlueCAN L
12
34
5
M12
500
+60
−0
9
20
13.5
9
4.5 dia.
4.5
73
4.5
dia.
9
dia.
30.5
272727
9
127
2
3
5
1
4
2754
33
1
5
15
PORT 1 PORT 2 PORT 3 PORT 4 PORT 5 PORT 6 PORT 7 PORT 8
Connections Diagram
152 Peripheral Devices
● Environment-resistive Models for Thick Wires with 7/8-16UN Mini Connectors
1
2
3
4
5
62.5
L
61.2
26 dia. 26 dia.
12 dia.
15
2
3
4
Thick Cable with Connectors on Both Ends (5 Conductors for Communications)
DCA2-5CN@@W1
Wiring
Terminal
No.
Color Name
1
- DRAIN
2
Red V+
3
Black V-
4
White CAN H
5
Blue CAN L
61.2
L
12 dia.
51
4
3
2
50
26 dia.
Thick Cable with Connector Socket on One End (5 Conductors for Communications)
DCA2-5CN@@F1
Wiring
Terminal
No.
Color Name
1
- DRAIN
2
Red V+
3
Black V-
4
White CAN H
5
Blue CAN L
62.5
L
12 dia.
15
2
3
4
50
26 dia.
Thick Cable with Connector Plug on One End (5 Conductors for Communications)
DCA2-5CN@@H1
Wiring
Terminal
No.
Color Name
1
- DRAIN
2
Red V+
3
Black V-
4
White CAN H
5
Blue CAN L
62.5
40.7
L
26 dia.
6 dia.
14.9 dia.
43
5
15
2
3
4
12
Thin Cable with Connectors on Both Ends (5 Conductors for Communications)
DCA1-5CN@@W5
Wiring
Terminal
No.
Color Name
1
- DRAIN
2
Red V+
3
Black V-
4
White CAN H
5
Blue CAN L
5
1
4
3
2
27
1.7
15
25
41
50
L
12 dia.
M20 × 1.5
20 dia. 2
+0.1
0
33 min.
Thin Cable with Panel-mounting Connector Socket on One End
(5 Conductors for Communications)
DCA2-5CNC5P1
Wiring
Terminal
No.
Color Name
1
- DRAIN
2
Red V+
3
Black V-
4
White CAN H
5
Blue CAN L
Panel Cutout Dimensions
Note: A rubber seal and nut for panel mounting are included.
Peripheral Devices 153
M20 × 1.5
O-ring
12 dia.
50
5
50046
25
15
4
4
1
2
5
3 (sequence pin)
Panel-mounting Connector (Plug) with 0.5 m Cable
DCA2-5CNC5M1
Wiring
Terminal
No.
Color Name
1
- DRAIN
2
Red V+
3
Black V-
4
White CAN H
5
Blue CAN L
Note: A nut is included.
D4N3-11
1
2
3
5
4
CN0
CN2
CN1
26 dia.
74.7
14.6
41.7
28.5
5
4
3
2
1
4
5
1
2
3
25.4
1
2
3
4
5
1
2
3
4
5
12345
Plug CN0 (IN) Socket CN2 (OUT)
Socket CN1 (OUT)
T-branch Connector (5 Conductors for Communications,
Thick Wire Branch Line)
DCN3-11
Wiring
Terminal No. Name
1
DRAIN
2
V+
3
V-
4
CAN H
5
CAN L
Connections Diagram
D4N3-12
1
2
3
5
4
26 dia.
74.7
25.4
CN0
5.5 dia.
CN2
CN1
14.6
37.6
31
4
5
2
28.5
3
4
5
1
2
1
2
3
4
5
1
2
3
4
5
12345
Plug CN0 (IN) Socket CN2 (OUT)
Socket CN1 (OUT)
T-branch Connector (5 Conductors for Communications,
Thin Wire Branch Line)
DCN3-12
Wiring
Terminal No. Name
1
DRAIN
2
V+
3
V-
4
CAN H
5
CAN L
Connections Diagram
