Environment-resistive Terminals with Transistors (High-function Type)
DRT2-
@
D08C(-1)/
@
D16C(-1)
Environment-resistive Terminals with Transistors (High-function Type)
DRT2-
@
D08C(-1)/
@
D16C(-1)
Environment-resistive (IP67) I/O
Terminals with Troubleshooting
Functions such as Sensor Power
Supply Short-circuit Detection
• Equipped with the standard Smart Slave functions that provide powerful
preventative maintenance and troubleshooting capabilities.
• High degree of environmental resistance with dust-proof and drip-proof
construction.
• Power supply wiring is not required for input devices.
• Connect heavy-load devices (up to 1.5 A).
• Power supply wiring is not required for input devices such as sensors. (Power supply wiring is required for output devices.)
• Detects ground faults or disconnects and notifies the Master.
Smart Slave Functions
Ordering Information
General Specifications
Contact operation counter Unit conduction time monitor Total ON time monitor Unit comments
Connected device comments
Network power supply voltage monitor
I/O power supply monitor function (output only) Communications error log function (output only)
Input filter (input only)
Sensor power supply short-circuit detection (input only)
Power-ON inrush current protection (input only)
Disconnected sensor detection (input only)
No need to wire input device power supply (input only)
Last maintenance date
External load short-circuit detection (output only)
Communications speed auto-detection
No need to wire Unit power supply
Specifications I/O connections
Rated internal circuit power
supply voltage
Rated I/O power supply voltage Model
Input
NPN (+ common)
8 points
Sensor I/O
connector
Supplied from the
communications connector
Supplied from the
communications connector
DRT2-ID08C
PNP (- common) DRT2-ID08C-1
Output
NPN (- common)
24 VDC
DRT2-OD08C
PNP (+ common) DRT2-OD08C-1
Input
NPN (+ common)
16 points
Supplied from the
communications connector
DRT2-HD16C
PNP (- common) DRT2-HD16C-1
Item Model DRT2-ID08C(-1) DRT2-HD16C(-1) DRT2-OD08C(-1)
Communications power supply voltage 11 to 25 VDC (Supplied from the communications connector)
I/O power supply voltage 20.4 to 26.4 VDC (24 VDC -15%/+10%)
Noise immunity Conforms to IEC 61000-4-4 2 kV (power line)
Communications power supply current
consumption
115mA max. (24 VDC)
90mA max. (11 VDC)
200mA max. (24 VDC)
130mA max. (11 VDC)
35mA max. (24 VDC)
60mA max. (11 VDC)
Vibration resistance
10 to 60 Hz, 0.7-mm double amplitude, 60 to 150 Hz, 50 m/s
2
for 80 min each in the X,
Y, and Z directions
Shock resistance 150 m/s
2
, 6 directions, 3 times each
Dielectric strength 500 VAC between isolated circuits
Insulation resistance 20 MΩ min. (between isolated circuits)
Ambient operating temperature -10°C to 55°C
Ambient operating humidity 25% to 85% (with no condensation)
Ambient operating atmosphere No corrosive gases
Ambient storage temperature -20°C to 65°C
Degree of protection IP67
Mounting method M5 screw mounting (front and back)
Mounting strength 100 N
Connector strength 30 N
Screw tightening torque
Round connectors (communications, supply voltage, and I/O): 0.39 to 0.49 N
·m
M5 (Unit mounting from front): 1.47 to 1.96 N
·m
Weight 340 g max. 390 g max.
I/O power supply connector -- 7/8-16UN
Communications connector M12
Environment-resistive Terminals with Transistors (High-function Type)
DRT2-
@
D08C(-1)/@D16C(-1) 49
Input Specifications
● 8-point Inputs Terminals with Transistors ● 16-point Inputs Terminals with Transistors
Output Specifications
● 8-point Outputs Terminals with Transistors
Note: Refer to Peripheral Devices on page 169 for information on applicable connectors.
Dimensions (Unit: mm)
Item Model DRT2-ID08C DRT2-ID08C-1
Internal I/O common
NPN PNP
I/O points 8 inputs
ON voltage
9 VDC min. (between
input and V terminal)
9 VDC min. (between
input and G terminal)
OFF voltage
5 VDC max. (between
input and V terminal)
5 VDC max. (between
input and G terminal)
OFF current 1.0 mA max.
Input current
3.0 mA min./point (at 11 VDC)
11.0 mA max./point (at 24 VDC)
Power supply voltage
for sensor
Communications power supply voltage +0 V max.
Communications power supply voltage -1.5 V min.
ON delay time 1.5 ms max.
OFF delay time 1.5 ms max.
Number of circuits per
common
8 per common
Item Model DRT2-HD16C DRT2-HD16C-1
Internal I/O common
NPN PNP
I/O points 16 inputs
ON voltage
9 VDC min. (between
input and V terminal)
9 VDC min. (between
input and G terminal)
OFF voltage
5 VDC max. (between
input and V terminal)
5 VDC max. (between
input and G terminal)
OFF current 1.0 mA max.
Input current
3.0 mA min./point (at 17 VDC)
11.0 mA max./point (at 24 VDC)
Power supply voltage
for sensor
Communications power supply voltage +0 V max.
Communications power supply voltage -1.5 V min.
ON delay time 1.5 ms max.
OFF delay time 1.5 ms max.
Number of circuits per
common
16 per common
Item Model DRT2-OD08C DRT2-OD08C-1
Internal I/O common
NPN PNP
I/O points 8 inputs
Rated output current 1.5 A per point, 8.0 A per common
Residual voltage
1.2 V max. (1.5 A DC
between each output
terminal and G)
1.2 V max. (1.5 A DC
between each output
terminal and V)
Leakage current 0.1 mA max.
I/O power supply
voltage
20.4 to 26.4 VDC (24 VDC -15%/+10%)
ON delay time 0.5 ms max.
OFF delay time 1.5 ms max.
Number of circuits per
common
8 per common
Two, 5.3 dia. or M5
175
60
37.7
27.3
24.3
26.6
165±0.2
● Environment-resistive Terminals (8 or 16 Inputs)
DRT2-ID08C
DRT2-ID08C-1
DRT2-HD16C
DRT2-HD16C-1
Mounting Hole Dimension
175
60
43.9
27.3
24.3
26.6
Two, 5.3 dia. or M5
165±0.2
● Environment-resistive Terminals (8 Outputs)
DRT2-OD08C
DRT2-OD08C-1
Mounting Hole Dimension
