F-17
Peripheral Devices
Standard Cables
P. 134
■ T-branch Taps
Parallel
Connectors
with Screws
DCN1-1C
■ Connectors
■ Power Supply Tap ■ Terminal-block Terminator ■ DeviceNet Standard Cables
Parallel
Connectors
with Screws
DCN1-2C
Orthogonal
Connectors
with Screws
DCN1-2R
Parallel Connector
with Screws
XW4B-05C1-H1-D
Multi-branch Parallel
Connector with Screws
XW4B-05C4-TF-D
Parallel
Connectors
with Screws
DCN1-3C
Parallel
Connectors
with Screws
DCN1-4C
Orthogonal
Connectors
with Screws
DCN1-4R
Multi-branch Parallel
Connector without Screws
XW4B-05C4-T-D
Orthogonal Connector
with Screws
XW4B-05C1-V1R-D
Parallel
Connectors
with Clamps
DCN1-1NC
Parallel
Connectors
with Clamps
DCN1-3NC
Parallel Connector with
Screw-less Clamps
XW4G-05C1-H1-D
Multi-branch Parallel
Connector with
Screw-less Clamps
XW4G-05C4-TF-D
DCN1-1P
DRS1-T
Thin Cable
DCA1-5C10(-B)
Thick Cable
DCA2-5C10(-B)
Overview
Introducing
DeviceNet Products
Network
Specifications
DRT2-series
Smart Slaves
SmartSlice
GRT1 Series
Intelligent
Slaves
Configurator
and Software
Peripheral
Devices
Ordering
Information
Master
Units
MULTIPLE I/O
TERMINAL Series
CIP Safety on
DeviceNet System
F-18
Peripheral Devices
Environment-resistive Peripheral Devices (M12 Thin Cable with Micro Connectors)
P. 144
Environment-resistive Peripheral Devices (Smartclick Thin Cable with Micro Connectors)
P. 145
Environment-resistive Peripheral Devices (7/8-16 UN Thick Cable with Mini Connectors)
P. 146
■ Shielded Connector Cables
■ Shielded Connector Cables
■ Shielded Assembly Connectors
■ Shielded Terminating Resistor
■ Shielded Terminating Resistor
DRS2-1
DRS2-2
DCA1-5CN@@W1
DCA1-5CN@@H1
DCA1-5CN@@F1
XS2G-D5S7 XS2C-D5S7
DCN2-1
■ Shielded Panel-mounting Connectors
XS2P-D522-2 XS2M-D524-4
■ Panel-mounting Connectors
DCA2-5CNC5P1 DCA2-5CNC5M1 XS4M-D521-1
DRS3-1
DCA2-5CN@@W1 DCA2-5CN@@H1
DCA2-5CN@@F1
DCN3-11
DCN3-12
■ Shielded Connector Cables
■ Shielded Branching Relay Box
DRS2-1S
DRS2-2S
■ Shielded Terminating Resistor
DCA1-5CS@@W1
DCN2-S4C5H1
DCA1-5CS@@H1
DCA1-5CS@@F1
DCN2-1S
DCN2-S8C5H1
■ Shielded T-branch
Tap Connector
■ Shielded T-branch
Tap Connector
■ Shielded T-branch Tap Connector
Product Lineup
F-19
Overview
Introducing
DeviceNet Products
Network
Specifications
DRT2-series
Smart Slaves
SmartSlice
GRT1 Series
Intelligent
Slaves
Configurator
and Software
Peripheral
Devices
Ordering
Information
Master
Units
MULTIPLE I/O
TERMINAL Series
CIP Safety on
DeviceNet System
Device
Device
Device
Device
Device
Device
Device Device
Device
Device
Device
Terminating
resistance
Ta p Ta p Ta p
Ta p
24-VDC power supply for network
Ta p
Device
Ta p
Trunk line length (100 m: 500 kbps; 250 m: 250 kbps; or 500 m: 125 kbps)
Multidrop
Star connections
T-branch
Branching to
branch lines
Item
Baud rate
Communication media
Baud rate
500 kbps
Communication distance
250 kbps
125 kbps
• Using a Special 5-wire Cable
Max. network length
100 m max.
250 m max. (See note2.)
500m max. (See note2.)
Branch line length
6 m max.
6 m max.
6 m max.
Total branch line length
39 m max.
78 m max.
156 m max.
Baud rate
500 kbps
250 kbps
125 kbps
• Using a Special 4-wire Cable
Max. network length
75 m max.
150 m max.
265 m max.
Branch line length
6 m max.
6 m max.
6 m max.
Total branch line length
35 m max.
48 m max.
135 m max.
Communications power supply
Specification
DeviceNet
Multidrop and T-branch connections can be combined (for trunk lines and branch lines).
125, 250, or 500 kbps
Special cable: 5-conductor cable (2 signal lines, 2 power lines and 1 shield)
Special Flat cable: 4-conductor cable (2 signal lines, 2 power lines)
24 VDC (external)
Max. number of connectable nodes
Note 1: Terminating resistance required on both ends of the trunk line.
2: These values apply to using Thick Cable on the trunk line. If Thin Cable is used, the value will be 100 m max.
64 Units (including Master Units, Slave Units and Configurator)
DeviceNet Network Specifications
Communications Specifications
Terminating
resistance
(Branch line length: 6 m max.)
Communication protocol
Connection method (See note1.)
Network Specifications
