62 Temperature Input Terminals DRT2-TS04@
Dimensions (Unit: mm)
Terminal Arrangement
DRT2-TS04T DRT2-TS04P
Wiring Diagrams
DRT2-TS04T (Thermocouple input) DRT2-TS04P (Platinum resistance thermometer input)
3.1
115
50
49.7
29.9
43.9
DRT2-TS04T
DRT2-TS04P
NC
NC
NC
NC
NC
NC
NC
IN0
+
IN0
-
NC
IN1
+
IN1
-
IN2
+
IN2
-
IN3
+
IN3
-
Cold junction compensator
Do not touch or remove the cold junction compensator.
Otherwise temperature data will not display properly.
NC
NC
NC
NC
IN2
b
IN2
B
IN3
b
IN3
B
IN3
A
IN2
A
NC
NC
IN0
b
IN0
B
IN1
b
IN1
B
IN1
A
IN0
A
NC
IN0
+
IN0
-
IN0
b
IN0
B
IN0
A
63
SmartSlice GRT1 Series
SmartSlice GRT1 Series.................................................................................. 64
■ What Is the SmartSlice GRT1 Series
■ System Configuration
■ Internal Circuit Configuration
DeviceNet Communications Unit..................................................................... 68
GRT1-DRT
SmartSlice I/O Units ........................................................................................ 70
64 SmartSlice GRT1 Series
SmartSlice GRT1 Series
DeviceNet-compliant Building-block I/O Terminals to Save
Space, Cut Costs, and Reduce Work.
What Is the SmartSlice GRT1 Series?
This SmartSlice GRT1 Series consists of building-block I/O Terminals that enable building flexible systems to
match the customer's applications with features such as I/O expansion using small numbers of points.
Connect up to
64 Units with up
to 1,024 points.
Building-block Remote
SmartSlice I/O Units with
2, 4, or 8 points per Unit.
DeviceNet Communications Unit
PLC
80 mm
15 mm
Analog I/O Units
GRT1-AD2
GRT1-DA2C
GRT1-DA2V
Digital I/O Units
GRT1-ID4(-1)
GRT1-OD4(-1)
GRT1-ID8(-1)
GRT1-OD8(-1)
GRT1-ROS2
GRT1-IA4-1
GRT1-IA4-2
Analog Temperature Input Units
GRT1-TS2T
GRT1-TS2P
GRT1-TS2PK
Counter Unit
GRT1-CT1(-1)
End Unit
GRT1-END
I/O Power Supply Units
GRT1-PD2
GRT1-PD2G
GRT1-PD8
GRT1-PC8
GRT1-DRT
