Dimensions
● Environment-resistive Connection Products (for Thin Cable, M12 Micro Connectors)
1
5
2
3
4
M12
M12
1
2
34
5
14.9 dia.
7 dia.
L (cable length)
44.7
40.7
14.9 dia.
Cables with Connectors on Both Ends
DCA1-5CN@@W1
Wiring
Terminal No. Color Name
1 - DRAIN
2RedV+
3BlackV-
4 White CAN H
5BlueCAN L
M12
3
4
12
5
L (cable length)
40.7
30 5
50
14.9 dia.
7 dia.
Cables with Connector on Single End (Socket)
DCA1-5CN@@F1
Wiring
Terminal No. Color Name
1 - DRAIN
2RedV+
3BlackV-
4 White CAN H
5BlueCAN L
1
5
2
3
4
7 dia.
L (cable length)
44.7
14.9 dia.
30 5
50
M12
Cables with Connector on Single End (Plug)
DCA1-5CN@@H1
Wiring
Terminal No. Color Name
1 - DRAIN
2RedV+
3BlackV-
4 White CAN H
5BlueCAN L
(56)
24.717.7
32.1
13.6
13.6
12
10
CN0
CN1
CN2
2
1
5
2
2
1
5
4
3
1
4
35
4
3
4.5 dia.
8 dia. (Countersinking: 2)
18
1
2
3
4
5
1
2
3
4
5
12345
Socket CN1
(
OUT
)
Socket CN2
(
OUT
)
Plug CN0
(
IN
)
12
4
M12
3
5
8.5
dia.
14.9 dia.
13.6
dia.
44.7
T-branch Connector
DCN2-1
Wiring
Terminal No. Name
1SHIELD
2V+
3V-
4CAN H
5CAN L
Connectors with Terminating Resistance
DRS2-1 (Plug)
DRS2-2 (Socket)
Connections Diagram Wiring
Note: Terminating resistance (121 Ω) is
connected between terminals 4
and 5.
Terminal No. Name
1 DRAIN : NC
2V+: NC
3V-: NC
4
CAN H :
CAN L :
121 Ω
5
Note: The diagram shows the DRS2-1 (plug).
Peripheral Devices 149
]
M12×1
