● Environment-resistive Models for Thin Wires with M12 Smart Click Microconnectors
* Robot cable type connectors with shielded cables (DCA1-5CN@@@1-R) are also available. Contact your OMRON sales representative for details.
● Cables with Connectors Compatible with MULTIPLE I/O TERMINAL Connectors
Models with Fujitsu Connectors
Product Appearance Specifications Model
Sealed T-branch Connector For 1 branch line DCN2-1S
Sealed Connector with Terminating
Resistor
Plug DRS2-1S
Socket DRS2-2S
Cables with Sealed Connectors *
Cable with connectors on both ends
Length: 0.5 m DCA1-5CSC5W1
Length: 1 m DCA1-5CS01W1
Length: 2 m DCA1-5CS02W1
Length: 3 m DCA1-5CS03W1
Length: 5 m DCA1-5CS05W1
Length: 10 m DCA1-5CS10W1
Cable with connector socket on one end
(socket)
Length: 0.5 m DCA1-5CSC5F1
Length: 1 m DCA1-5CS01F1
Length: 2 m DCA1-5CS02F1
Length: 3 m DCA1-5CS03F1
Length: 5 m DCA1-5CS05F1
Length: 10 m DCA1-5CS10F1
Cable with connector socket on one end
(plug)
Length: 0.5 m DCA1-5CSC5H
Length: 1 m DCA1-5CS01H1
Length: 2 m DCA1-5CS02H1
Length: 3 m DCA1-5CS03H1
Length: 5 m DCA1-5CS05H1
Length: 10 m DCA1-5CS10H1
Shielded Branch Relay Box
4 ports 0.5-m cable DCN2-S4C5H1
8 ports 0.5-m cable DCN2-S8C5H1
Product Appearance Cable length L (mm) Model
Cable with Connectors
XW2Z-R@C
32 inputs
A: 1,000, B: 750 XW2Z-RI100C-75
A: 1,500, B: 1,250 XW2Z-RI150C-125
A: 2,000, B: 1,750 XW2Z-RI200C-175
A: 3,000, B: 2,750 XW2Z-RI300C-275
A: 5,000, B: 4,750 XW2Z-RI500C-475
32 outputs
A: 1,000, B: 750 XW2Z-RO100C-75
A: 1,500, B: 1,250 XW2Z-RO150C-125
A: 2,000, B: 1,750 XW2Z-RO200C-175
A: 3,000, B: 2,750 XW2Z-RO300C-275
A: 5,000, B: 4,750 XW2Z-RO500C-475
16 I/O points
1,000
XW2Z-R100C
1,500
XW2Z-R150C
2,000
XW2Z-R200C
3,000
XW2Z-R300C
5,000
XW2Z-R500C
Cable with Connectors
XW2Z
16 I/O points
500
XW2Z-050A
1,000
XW2Z-100A
1,500
XW2Z-150A
2,000
XW2Z-200A
3,000
XW2Z-300A
5,000
XW2Z-500A
32 I/O points
500
XW2Z-050B
1,000
XW2Z-100B
1,500
XW2Z-150B
2,000
XW2Z-200B
3,000
XW2Z-300B
5,000
XW2Z-500B
A
B
