OPTIMA PROM SOFTWARE
Optima User Manual
59
8-Bit Merge Low and High
This option is used to merge two 8-bit data files into one 16-bit data file, allowing a
16-bit device to be programmed.
To merge two 8-bit files into one 16-bit file, follow this four step process:
1. Select the first 8-bit file, choose 8-Bit Merge Low, and load your file.
The 8-bit data will be loaded at all the even addresses (shown in bold below).
2. Select the second 8-bit file, choose 8-Bit Merge High, and load the file.
The 8-bit data will be loaded at all the odd addresses. (shown in italics below).
3. Program the 16-bit memory device.
4. Save the newly created 16-bit data file.
Example 4: 8-Bit Merge Low and High
File Data Optima Ram Buffer
$A000, (8-Bit file one) Address Data
00 01 02 03 04 05 06 07 0000 00
0001 00
$A008, 0002 01
08 09 0A 0B 0C 0D 0E 0F 0003 11
0004 02
$A000, (8 Bit file two) 0005 22
00 11 22 33 44 55 66 77 0006 03
0007 33
$A008, 0008 04
88 99 AA BB CC DD EE FF 0009 44
000A 05
000B 55
000C 06
000D 66
000E 07
000F 77
OPTIMA PROM SOFTWARE
Optima User Manual
60
16-Bit Even and Odd
This option is used to split a 16-bit data file into two 8-bit data files.
To split a 16-bit data file into two 8-bit data files, follow this four step process:
1. Select the 16-bit data file that is to be split into two 8-bit files, select 16-Bit Even,
and load the file.
All the even data bytes will be loaded into the Optima Ram Buffer (as shown in
bold below).
2. Program the 8-bit memory device.
3. Repeat the file download operation, but select 16- Bit Odd.
All the odd data bytes will be loaded into the Optima Ram Buffer (shown in
italics below).
4. Program the second 8 bit memory device.
Example 5: 16-Bit Even and Odd
File Data Optima Ram Buffer Optima Ram Buffer
16-Bit Even Selected 16-Bit Odd Selected
$A000, (8-Bit file one) Address Data Data
00 01 02 03 04 05 06 07 0000 00 01
0001 02 03
$A008, 0002 04 05
08 09 0A 0B 0C 0D 0E 0F 0003 06 07
0004 08 09
$A010, 0005 0A 0B
00 11 22 33 44 55 66 77 0006 0C 0D
0007 0E 0F
$A018, 0008 00 11
88 99 AA BB CC DD EE FF 0009 22 33
000A 44 55
000B 66 77
000C 88 99
000D AA BB
000E CC DD
000F EE FF
OPTIMA PROM SOFTWARE
Optima User Manual
61
32-Bit Byte0…Byte3
This option is used to split a 32-bit data file into four 8-bit data files.
To split a 32-bit data file into four 8-bit data files, follow this eight-step process:
1. Select the 32-Bit data file that is to be split into four 8-bit files, select 32-Bit Byte
0, and load the file. Data bytes D0-D7 will be loaded into Optima Ram Buffer
(shown in bold).
2. Program the first 8-bit memory device.
3. Repeat the file download operation, and select 32-Bit Byte 1.
Data bytes D8-D15 will be loaded into the Ram Buffer (shown in italics).
4. Program the second 8-bit device.
5. Repeat the file download operation, and select 32-Bit Byte 2.
Data bytes D16-D23 will be loaded into the Ram Buffer (shown in underline).
6. Program the third 8-bit device.
7. Repeat the file download operation a forth time, and select 32-Bit Byte 3.
Data bytes D24-D31 will be loaded into the Ram Buffer (shown in regular).
8. Program the fourth 8-bit device.
Example 6: 32-Bit Byte0…Byte3
File Data Ram Buffer
Byte 0 Byte 1 Byte 2 Byte 3
$A000, Address Data Data Data Data
00 01 02 03 04 05 06
07 0000 00 01 02 03
0001 04 05 06 07
$A008, 0002 08 09 0A 0B
08 09 0A 0B 0C 0D 0E
0F0003 0C 0D 0E 0F
0004 00 11 22 33
$A010, 0005 44 55 66 77
00 11 22 33 44 55 66
77 0006 88 99 AA BB
0007 CC DD EE FF
$A018,
88 99 AA BB CC DD EE
FF
